SIMATIC ET 200PA SMART+ AI 16xI 2-wire PA Analog Input Module
Siemens 6DL1164-6GH00-0PH1 is an AI 16xI 2-wire PA analog input module for the SIMATIC ET 200PA SMART+ distributed I/O system. It acquires sixteen two-wire current signals for process automation and supports 0–20 mA and 4–20 mA measurement ranges with channel-selectable filtering. The module is intended for structured field-signal integration where dependable current measurement, channel diagnostics and configuration in RUN are important. Before replacement, verify the complete article number, terminal-block arrangement, field wiring, configured measuring range, firmware support, project parameters and whether the station design requires module redundancy.
| Product Condition | Original new |
|---|---|
| Availability | In stock |
| Warranty | With 1 year warranty |
| Shipping | Worldwide shipping options available |
Condition, availability and warranty are Stockoems commercial information, not manufacturer commitments.
| Manufacturer | Siemens |
|---|---|
| Complete Part Number | 6DL1164-6GH00-0PH1 |
| Product Type | AI 16xI 2-wire PA analog input module |
| System | SIMATIC ET 200PA SMART+ |
| Analog Inputs | 16 current inputs |
| Input Ranges | 0–20 mA and 4–20 mA |
| Input Resistance | 250 ohms |
| Resolution | Up to 16 bit including sign |
| Minimum Cycle Time | 400 ms for all channels |
| Rated Supply Voltage | 24 V DC (19.2–28.8 V permissible) |
| Rated Current Consumption | 350 mA |
| Typical Power Loss | 0.6 W |
| Address Space | 34 bytes: 32 input bytes plus 2 bytes for QI information |
| Configuration in RUN | Reparameterization supported |
| Redundancy Capability | No |
| Maximum Cable Length | 800 m shielded; 200 m unshielded |
| Country of Origin | GERMANY |
| Application | Engineering Relevance |
|---|---|
| ET 200PA SMART+ stations | Sixteen two-wire current signals for distributed process I/O |
| Process instrumentation | 0–20 mA and 4–20 mA acquisition with configurable filtering |
| Maintenance and replacement | Match terminal block, wiring, firmware and project configuration |
| Architecture check | This article is not specified for redundant operation |
