Siemens 6ES7322-1BH01-0AA0 SM322 Digital Output Module

Siemens 6ES7322-1BH01-0AA0
Siemens 6ES7322-1BH01-0AA0
Siemens 6ES7322-1BH01-0AA0

6ES7322-1BH01-0AA0 Product datasheet

Model number:

6ES7322-1BH01-0AA0



Module Type:

SM322 Digital Output Module

Manufacture:

Siemens



Condition:

Brand New

Range of Product:

Siemens



Lead time:

In Stock

Weight:

0.24 kg



HS CODE:

8537101190

Dimension:

10.5x12.5x4cm



MOQ:

1

Product Origin:

GERMANY



System:

PLC

Discontinued on:

Active



Communication Service:

Ethernet router



6ES7322-1BH01-0AA0 Functional Description


The SM322 Digital Output Module 6ES7322-1BH01-0AA0 Siemens is a high-performance digital output module designed for SIMATIC S7-300 PLC systems, featuring 16 isolated channels with 24V DC/0.5A transistor outputs in a compact form factor. This module provides electrical isolation (500V AC) between the backplane and field side, ensuring reliable operation in industrial environments. The Siemens Digital Output Module  6ES7322-1BH01-0AA0 offers a total current capacity of 4A per group (8A per module), making it suitable for controlling various industrial actuators and indicators. Its single 20-pole front connector simplifies wiring while maintaining high-density connectivity.



Engineered for industrial durability, the Siemens 6ES7322-1BH01-0AA0 PDF includes built-in short-circuit protection and diagnostic capabilities for each output channel. The module operates within a wide load voltage range of 20.4-28.8V DC, accommodating typical industrial power fluctuations. With a low power consumption of 1.5W, the 6ES7322-1BH01-0AA0 Siemens I/O Modules efficiently manages energy usage while delivering stable performance. Its robust design ensures compatibility with standard SIMATIC S7-300 racks and backplanes, enabling seamless integration into existing automation systems.



The Siemens 6ES7322-1BH01-0AA0 SIMATIC S7-300 Digital Output Module demonstrates particular value in applications requiring multiple medium-current outputs, such as conveyor controls, packaging machinery, and material handling systems. Its isolated outputs prevent ground loops and protect the PLC backplane from electrical disturbances in the field wiring. The module's grouping configuration (two groups of 8 channels) allows flexible load distribution, while the high total current capacity supports simultaneous operation of multiple devices.



As a proven component of Siemens' automation portfolio, the 6ES7322-1BH01-0AA0 SM322 Digital Output Module  continues to deliver reliable performance in demanding industrial applications. Its combination of channel density, output capacity, and isolation protection makes it an ideal choice for both new installations and system upgrades. The module maintains compatibility with the full range of S7-300 CPUs and can be easily configured using STEP 7 software, ensuring efficient integration into diverse automation projects.
