Siemens 6ES7288-2DT08-0AA0 SIMATIC S7-200 SMART EM DT08 Transistor Output Module

Eight 24 V DC sourcing transistor outputs provide fast switching for compatible S7-200 SMART field loads.

Product Overview

Siemens 6ES7288-2DT08-0AA0 is the SIMATIC S7-200 SMART EM DT08 transistor output expansion module. It adds eight sourcing 24 V DC digital outputs rated up to 0.75 A per channel for documented resistive loads. Its microsecond-scale switching response suits control tasks that require faster operation than relay contacts. The module supports planned panel expansion, machine maintenance and like-for-like replacement. Before ordering, verify the complete article number, load current, group current, external protection, output common, terminal allocation and available expansion position in the target S7-200 SMART system.

Key Product Information

Technical Data Summary

Four-Point Signal Route

Features and Benefits

• Eight sourcing transistor outputs support fast DC switching.
• Microsecond-scale output response suits time-sensitive control.
• Two output groups simplify planned common and load distribution.
• Channel-status LEDs assist commissioning and fault isolation.

Applications

Installation, Wiring and Compatibility

1. Confirm 24 V DC load supply polarity and output commons.
2. Check channel and group current against published limits.
3. Provide suitable protection because internal short-circuit protection is not listed.
4. Match terminal allocation and project configuration before energizing.

Compatibility notice: Confirm the complete suffix, supply and signal levels, terminal assignment, module position and the original project documentation. Please contact us to confirm the exact revision, firmware version, condition and availability before ordering.
