Sixteen 24 V DC sink/source digital inputs extend field-status acquisition for a documented S7-200 SMART control system.
Siemens 6ES7288-2DE16-0AA0 is the SIMATIC S7-200 SMART EM DE16 digital input expansion module. It adds sixteen 24 V DC inputs for receiving discrete field states from compatible switches and sensors. The module suits control-panel expansion, maintenance replacement and projects that need additional input capacity without changing the selected CPU family. Input channels are arranged in four groups and support the documented filter-time selections. Before ordering, compare the complete article number, 24 V DC input requirements, available expansion position, terminal arrangement and the existing STEP 7 Micro/WIN SMART project documentation.
| Field | Confirmed information |
|---|---|
| Manufacturer | Siemens |
| Complete Part Number | 6ES7288-2DE16-0AA0 |
| Product Type | SIMATIC S7-200 SMART EM DE16 Digital Input Module |
| Series | SIMATIC S7-200 SMART |
| Product Condition | NEW |
| Hardware Revision | Contact us to confirm. |
| Firmware / Software Version | Contact us to confirm. |
| Country of Origin | GERMANY |
| Compatibility | Confirm CPU, expansion layout and project configuration before ordering. |
| Availability / Warranty | With 1 year warranty |
| Shipping | Worldwide shipping options confirmed with quotation. |
| Parameter | Value |
|---|---|
| I/O configuration | 16 digital inputs; no digital outputs |
| Input type | 24 V DC sink/source; IEC Type 1 sink |
| Input grouping | 4 groups |
| Signal 1 range | +15 to +30 V DC |
| Signal 0 level | Less than 5 V DC |
| Input delay | 200 µs maximum, 0 to 1 and 1 to 0 |
| Filter selections | 0.2 to 12.8 ms, selectable in groups of four |
| Dimensions (W × H × D) | 45 × 100 × 81 mm |
| Approximate weight | 176 g |
| 01
Field switch or sensor
|
02
24 V DC input wiring
|
03
EM DE16 input channel
|
04
S7-200 SMART CPU logic
|
| Machine status and limit-switch acquisition | Production-line sensor expansion | Control-panel retrofit or capacity extension | Maintenance replacement in documented S7-200 SMART systems |
Compatibility notice: Confirm the complete suffix, supply and signal levels, terminal assignment, module position and the original project documentation. Please contact us to confirm the exact revision, firmware version, condition and availability before ordering.
| 1 | Complete article number 6ES7288-2DE16-0AA0 |
| 2 | Required quantity and destination country |
| 3 | CPU model and available expansion position |
| 4 | Input wiring diagram and field-signal type |
| 5 | Product and label photos when replacing an installed module |
Send us the complete part number, required quantity, destination country and product label photos. Our team will check availability, condition, compatibility requirements and shipping options.
Our workflow supports engineers and buyers from exact model verification through protected international dispatch. Commercial terms are confirmed in writing before the order is placed.
| 01 | Model and suffix verification Compare the complete Siemens article number and product label. |
| 02 | Condition confirmation Supply as NEW and confirm available product photos when requested. |
| 03 | Technical compatibility review Review the S7-200 SMART CPU, expansion layout, EM DE16 I/O type and project requirements. |
| 04 | Packing and documentation Protect terminals and housing; prepare shipment and customs documents. |
| 05 | Worldwide shipping Confirm carrier, freight cost, tracking and destination requirements. |
| 06 | Warranty and returns Provide a 1-year warranty under written terms and a documented return-authorization process. |
Stockoems is operated by Apter Power Limited and is an independent reseller of industrial automation products. Manufacturer names and trademarks are used for identification purposes only.
Send the complete part number, quantity, destination country and available label photos for verification.
