Product Overview

The Schneider Digital Outputs Module Transistor BMXDDO1602 is a Modicon X80 discrete output module featuring 16 solid-state, 24V DC positive transistor outputs with overload, short-circuit, and reverse polarity protection.

Features and benefits

• High-Density Outputs: 16 solid-state, 24V DC positive transistor outputs in a compact module.

• Robust Protection: Comprehensive safeguards including short-circuit, overload, overvoltage, and reverse polarity protection.

• High Current Capacity: Supports 0.5A per channel with 10A maximum per module; up to 2 outputs can be paralleled.

• Fast Response: Quick 1.2 ms response time for time-sensitive industrial applications.

• Diagnostic Capabilities: Voltage detection thresholds (<14V fault, >18V OK) for preactuator monitoring.

• Rugged Design: Withstands 3gn vibration, 30gn shock, and operates at 0-60°C with IP20 protection.

FAQ

Q1: What is the Schneider BMXDDO1602?

A1: It is a Modicon X80 discrete output module with 16 solid-state, 24V DC positive transistor outputs.

Q2: What protection features does the BMXDDO1602 include?

A2: It includes short-circuit, overload, overvoltage, and reverse polarity protection with electronic circuit breaker.

Q3: What is the current rating per channel?

A3: Each channel supports 0.5A, with a maximum module current of 10A.

Q4: Can outputs be paralleled on this module?

A4: Yes, up to 2 outputs can be paralleled for higher current requirements.

Q5: What is the response time for outputs?

A5: The response time is 1.2 ms, suitable for fast-switching applications.
