Schneider ABE7H16R11 Interface Modules

Inquiry now

ABE7H16R11 Product datasheet

Model number:	ABE7H16R11	Module Type：	Interface Modules
Manufacture:	Schneider Electric	Condition：	Brand New
Range of Product:	Schneider Electric	Lead time：	In Stock
Weight:	1.18 kg	HS CODE：	8537101190
Dimension:	24.2x12.6x10.5cm	MOQ:	1
Product Origin:	France	System：	PLC
Discontinued on:	active	Communication Service:	Ethernet router

ABE7H16R11 Functional Description

The ABE7H16R11 Schneider Electric is a passive discrete I/O sub-base designed for seamless integration into industrial control systems. With a rated supply voltage of 19-30V DC (conforming to IEC 61131-2), it ensures reliable operation in demanding environments. This model features 16 channels, each with a single terminal, making it ideal for distributed control applications. The ABE7H16R11 Interface Modules Schneider supports multiple wiring configurations, including flexible and solid conductors, enhancing installation flexibility.

Equipped with screw-type terminals, the Interface Modules ABE7H16R11 Schneider accommodates a wide range of wire sizes (up to 2.5 mm²). It includes short-circuit protection via a 2A internal fuse, ensuring safety for connected PLCs. Each channel has an LED indicator for real-time status monitoring, while a green power LED confirms operational readiness. The Schneider ABE7H16R11 also features a 20-pin HE-10 connector, enabling secure and efficient signal transmission.

The Schneider ABE7H16R11 in stock can be mounted on a 35mm DIN rail or a solid plate using a fixing kit, offering flexibility in panel installation. Its compact 125mm width and lightweight 0.274kg design make it suitable for space-constrained applications. With an insulation voltage of 2000V and Installation Category II compliance (IEC 60664-1), it guarantees durability and electrical safety.

Designed for DC supply systems, the Schneider ABE7H16R11 Interface Modules delivers stable performance with a maximum current of 1.8A (0.5A per channel). Its low voltage drop (0.3V) ensures efficient power distribution. Whether used in manufacturing, energy, or building automation, the Schneider ABE7H16R11 provides a dependable I/O interface solution for enhanced system control.

If you have other request contact our team to get customized service

One Year Warranty

We offer a one-year warranty for any quality issues with our products. If you encounter any defects or malfunctions during this period, please contact us for prompt resolution. Our warranty covers repairs or replacements, ensuring your satisfaction and peace of mind.
Shipping & Delivery

We have 10 years experience with leading logistics companies like FedEx, DHL, and SF, ensuring efficient and reliable shipping solutions. Our extensive experience in working with these carriers allows us to offer fast, secure delivery services, tailored to meet the diverse needs of our customers.
Payment Method

We accept a variety of payment methods, including T/T Bank Transfer, Alipay, and more, providing flexible options to suit our customers' preferences. This ensures a convenient and secure transaction process for all orders.

How Can I Get Your Support?

Call +86 18159889985 to be connected with our Manager Stella

Email to sales6@apterpower.com get your best quotation

For the quick assistance message us on WhatsApp at +86 18159889985 now!

You can also reach me via Skype: live:ariatang111 or WeChat: zxd18159889985!

SCHNEIDER	MPCYT90NAN00N	SCHNEIDER	170XTS02100	SCHNEIDER	170AAO92100
SCHNEIDER	ME4U07AAA	SCHNEIDER	170XTS00100	SCHNEIDER	170AAI14000
SCHNEIDER	LXM15MD28N4	SCHNEIDER	170PNT11020	SCHNEIDER	140XTS00200
SCHNEIDER	BCH2MM0813CA6C	SCHNEIDER	170MCI02120	SCHNEIDER	140XCP51000
SCHNEIDER	ATV61HD37N4	SCHNEIDER	170MCI00702	SCHNEIDER	140XCP50000
SCHNEIDER	AS-S908-110	SCHNEIDER	170MCI00100	SCHNEIDER	140XCA71706
SCHNEIDER	AS-P890-000	SCHNEIDER	170M6467 3AUA0000062487	SCHNEIDER	140XBP01600
SCHNEIDER	990XCP98000	SCHNEIDER	170INT11003	SCHNEIDER	140XBP01000
SCHNEIDER	171CCS78000	SCHNEIDER	170ADO35000	SCHNEIDER	140XBP00600
SCHNEIDER	171CCC76010	SCHNEIDER	170ADI35000	SCHNEIDER	140XBE10000

Schneider Electric Interface Modules

Schneider Electric's Interface Modules provide seamless integration between control systems and field devices, ensuring efficient signal transmission and robust performance in industrial environments. Designed for versatility, these modules support a wide range of I/O configurations, including digital, analog, and specialty signals, making them ideal for PLCs, motor control, and process automation.

Featuring high-density terminal blocks, LED status indicators, and short-circuit protection, Schneider’s Interface Modules enhance system reliability and simplify troubleshooting. Models such as the Advantys, Modicon, and Telemecanique series offer flexible mounting options, including DIN rail and panel installation, catering to diverse application needs.

With wide voltage compatibility (12-240V AC/DC) and compliance with IEC, UL, and CE standards, Schneider Interface Modules ensure safety and durability. Their compact, modular design allows for easy expansion, reducing downtime and improving productivity in automation systems. Whether for discrete or complex control tasks, Schneider’s solutions deliver precision and dependability.
