5464-653 Overview

The Woodward 32 CH DISCRETE OUT 5464-653 is a discrete output module with 64 open-drain channels and a 5 ms update time. It drives Woodward relay modules, lacks potentiometers, requires no calibration, and is directly replaceable with no system modifications.

5464-653 Key Features

Function: 64-channel discrete output module for MicroNet control systems.

Driver: Open-drain drivers compatible with Woodward relay interface modules.

Performance: 5 ms update time; no potentiometers or calibration required.

Safety: Outputs automatically turn off upon CPU communication loss.

Installation: Direct replacement design; interfaces with 16/32-channel relay modules.

FAQ

Q1: What is the Woodward 5464-653?

A1: It is a 64-channel discrete output module for Woodward MicroNet control systems.

Q2: What is its key performance feature?

A2: It has a fast 5 ms update time and requires no calibration.

Q3: What happens if communication with the CPU is lost?

A3: All outputs are automatically turned off as a safety feature.

Q4: How is it installed and replaced?

A4: It is a plug-in module designed for direct, unmodified replacement in the chassis.

Q5: What does it drive in the field?

A5: It generates relay driver signals to interface with Woodward 16 or 32-channel relay modules.
