Siemens 6SL3225-0BE27-5AA1 PM250 power module provides regenerative 380–480 V drive power for SINAMICS G120 systems.
Siemens 6SL3225-0BE27-5AA1 is a SINAMICS G120 PM250 power module for three-phase 380–480 V AC drive systems. The module combines motor power conversion with energy recovery and an integrated Class A filter. Siemens specifies 7.5 kW operation under high-overload duty and 11 kW under low-overload duty, with operating limits dependent on the selected load profile. Its FSC frame and IP20 construction support control-cabinet installation. Before replacement, buyers should verify the complete suffix, mains range, duty rating, frame size, cooling conditions, and compatibility with the intended SINAMICS control unit and operator panel.
| Product Condition | Original new |
| Availability | In stock |
| Official Lifecycle | PM300: Active Product |
| Warranty | With 1 year warranty |
| Shipping | Worldwide shipping options available |
Condition, availability and warranty are Stockoems commercial information, not manufacturer commitments.
| Item | Officially Confirmed Data |
|---|---|
| Manufacturer | Siemens |
| Complete Part Number | 6SL3225-0BE27-5AA1 |
| Product Type | SINAMICS G120 PM250 power module |
| Drive Function | Energy recovery with integrated Class A filter |
| Input Supply | 380–480 V 3 AC, +10% / −10%, 47–63 Hz |
| High-Overload Rating | 7.5 kW; 200% for 3 s, 150% for 57 s, 100% for 240 s |
| Low-Overload Rating | 11 kW; 150% for 3 s, 110% for 57 s, 100% for 240 s |
| Frame Size | FSC |
| Degree of Protection | IP20 without Control Unit and BOP |
| Dimensions (H × W × D) | 334 × 189 × 185 mm |
| Country of Origin | GERMANY |
| Application | Fit Consideration |
|---|---|
| Regenerative drive systems | Returns braking energy to the supply in suitable SINAMICS G120 installations. |
| Conveyors and material handling | Supports controlled motor operation where acceleration and braking cycles must be reviewed. |
| Pumps and fans | Used where the verified voltage range and duty profile match the project. |
| Maintenance replacement | Replaces an installed PM250 only after suffix, frame, rating and control-unit checks. |
Siemens identifies 6SL3225-0BE27-5AA1 as PM300: Active Product. This wording is reproduced without converting it into a discontinuation claim.
It identifies the complete Siemens order number for this SINAMICS G120 PM250 power module and its exact configuration.
Siemens specifies 380–480 V three-phase AC, with +10% / −10% tolerance and 47–63 Hz frequency.
Yes. Siemens describes this PM250 configuration as capable of energy recovery.
The official data lists 7.5 kW for high-overload duty and 11 kW for low-overload duty; the project duty profile must be checked.
No discontinuation wording is assigned here. Siemens identifies it as PM300: Active Product.
Verify the suffix, mains data, duty profile, FSC frame, cooling conditions, Control Unit, BOP and terminal arrangement.
Send us the complete part number, required quantity, destination country and product label photos. Our team will check availability, condition, compatibility requirements and shipping options.
Email: sales6@apterpower.com WhatsApp: +86 18159889985
Structured verification, inspection coordination, protective handling and worldwide logistics for 6SL3225-0BE27-5AA1.
| Checkpoint | What We Review |
|---|---|
| Model and suffix verification | The complete 6SL3225-0BE27-5AA1 code and requested quantity. |
| Condition confirmation | Housing or board condition, connectors, visible labels and packaging evidence. |
| Technical compatibility review | The buyer’s SINAMICS G120 PM250 environment, interfaces, supply data, installed hardware and project requirements. |
| Product and label photo confirmation | Readable order-code, connector, hardware-condition and packaging images when available. |
The product and exposed connectors are protected against impact, moisture and uncontrolled movement.
Shipping options are coordinated after destination, quantity, packaging and documentation needs are reviewed.
Tracking details are shared after carrier acceptance for traceable logistics follow-up.
Commercial documents are prepared according to the confirmed destination and transaction scope.
Our workflow connects model review, label verification, visual inspection, packaging checks, logistics coordination and document preparation in one procurement record. Written warranty terms are supplied with the confirmed transaction. Any return must follow the return authorization process before goods are sent back. After-sales response is coordinated through the same sales channel using the order code, shipment details, photographs and a clear issue description.
Look for exact model and suffix verification, readable label evidence, clear condition terms, compatibility questions, written warranty terms and traceable communication.
Request the complete order code, quantity, condition statement, inspection photographs when available, packaging plan, shipping options, documentation scope and return terms.
Match the complete order number and suffix exactly. Confirm 380–480 V AC supply and 47–63 Hz mains conditions. Verify whether the project uses high-overload or low-overload duty. Check FSC dimensions, cabinet clearance and cooling environment.
Risk signals include altered suffixes, unreadable labels, copied data from a different model, unsupported compatibility claims, missing return terms and unverified delivery promises.
Send the complete part number, required quantity, destination country and available product or label photos for a structured procurement review.
Email: sales6@apterpower.com WhatsApp: +86 18159889985
