Unfiltered SINAMICS PM240-2 power module for 380-480 V three-phase motor drive applications.
Siemens 6SL3210-1PE21-8UL0 is a SINAMICS PM240-2 power module for modular motor drive systems. The unfiltered unit accepts 380 to 480 V three-phase AC and includes an integrated braking chopper. Siemens rates it for 5.5 kW high-overload duty and 7.5 kW low-overload duty, with frame size FSB and IP20 protection. It is supplied without a Control Unit or operator panel and is approved for Control Unit firmware V4.6 or later. Procurement should verify the complete suffix, line voltage, overload profile, motor current, Control Unit, firmware, braking arrangement, EMC design, enclosure cooling and mechanical dimensions before installation.
| Product Condition | Original new |
|---|---|
| Availability | In stock |
| Official Lifecycle | Active Product |
| Warranty | With 1 year warranty |
| Shipping | Worldwide shipping options available |
Condition, availability and warranty are Stockoems commercial information, not manufacturer commitments.
| Manufacturer | Siemens |
|---|---|
| Article Number | 6SL3210-1PE21-8UL0 |
| Product Type | SINAMICS PM240-2 power module |
| Drive Family | SINAMICS G120 / S120 blocksize format |
| Line Input | 3 AC 380 to 480 V, +10% / -10% |
| Line Frequency | 47 to 63 Hz |
| Line Filter | Without integrated filter |
| Braking Function | Integrated braking chopper |
| High-Overload Power | 5.5 kW |
| High-Overload Profile | 200% for 3 s; 150% for 57 s; 100% for 240 s |
| Low-Overload Power | 7.5 kW |
| Low-Overload Profile | 150% for 3 s; 110% for 57 s; 100% for 240 s |
| Frame Size | FSB |
| Degree of Protection | IP20 |
| Dimensions | 291 x 100 x 165 mm |
| Ambient Temperature | -10 to +50 °C high overload; -10 to +40 °C low overload |
| Control Unit Requirement | Supplied without Control Unit or operator panel |
| Minimum CU Firmware | V4.6 |
| Efficiency Class | IE2 |
| System Role | Power stage for modular SINAMICS motor drive systems |
|---|---|
| Electrical Fit | 380-480 V three-phase AC installations |
| Typical Use | Variable-speed control of industrial motors with dynamic braking requirements |
| System Completion | Requires a compatible Control Unit, operator interface and engineered drive components |
Siemens currently lists 6SL3210-1PE21-8UL0 as an Active Product. The lifecycle status applies to this complete article number and should not be inferred from adjacent PM240-2 variants.
It is an unfiltered SINAMICS PM240-2 power module with an integrated braking chopper.
Siemens rates it at 5.5 kW for high-overload duty and 7.5 kW for low-overload duty.
The module is designed for 380 to 480 V three-phase AC at 47 to 63 Hz.
Siemens lists the complete article number as Active Product.
Check motor data, overload duty, Control Unit, firmware, braking components, EMC design, cooling and dimensions.
