One configurable analog command channel in the CPU signal-board format.
Siemens 6ES7288-5AQ01-0AA0 is the SIMATIC S7-200 SMART SB AQ01 signal board for adding one analog output to a compatible CPU configuration. The channel can be configured for voltage or current output, making the board suitable for compact setpoint and reference-signal duties where cabinet space is limited. It is relevant to machine upgrades, replacement planning and small control panels that need one additional analog command. Before ordering, confirm the complete suffix, CPU signal-board support, selected output range, connected load, wiring arrangement and the required hardware revision.
| Information field | Confirmed detail |
|---|---|
| Manufacturer | Siemens |
| Complete part number | 6ES7288-5AQ01-0AA0 |
| Product type | SB AQ01 Analog Output Signal Board |
| Series | SIMATIC S7-200 SMART |
| Product condition | NEW |
| Country of origin | GERMANY |
| Availability / Warranty | With 1 year warranty |
| Output channels | 1 analog output |
| Selectable signal | Voltage or current |
| Voltage range | ±10 V DC |
| Current range | 0–20 mA |
| Resolution | 12 bit voltage; 11 bit current |
| Typical power loss | 1.5 W |
| Diagnostics | Wire-break and short-circuit diagnostics supported |
| Protection | IP20 |
| Dimensions | 35 × 52.2 × 16 mm |
| Approximate weight | 17.4 g |
Confirm voltage or current operation against the receiving device.
Assign the output word and engineering scale in the CPU project.
Check load, polarity, shielding and common reference before energizing.
Use the available status and diagnostic indications during commissioning.
Confirm that the selected S7-200 SMART CPU accepts the signal-board format and that the connected load matches the configured ±10 V DC or 0–20 mA range. Please contact us to confirm the exact revision, firmware version, condition and availability before ordering.
Condition is confirmed in the written quotation. Incoming checks can include order-number verification, exterior inspection, label and serial-number recording, accessory review and applicable functional testing. Product and label photos can be provided before shipment when available.
A: The SB AQ01 supports one configurable analog output. Confirm the project parameterization and connected load before wiring.
A: Compare the complete article number, CPU support, output range, wiring, hardware revision and original label.
A: Official Siemens data lists diagnostic capability including wire-break and short-circuit monitoring. Verify the active configuration in the project.
A: Yes. Request current product and label photos with the quotation so the suffix and visible condition can be reviewed.
A: Worldwide shipping can be arranged after destination, packing requirements, dimensions and trade terms are confirmed.
Send us the complete part number, required quantity, destination country and product label photos. Our team will check availability, condition, compatibility requirements and shipping options.
Email: sales6@apterpower.comWhatsApp: +86 18159889985Our service workflow for 6ES7288-5AQ01-0AA0 helps maintenance and procurement teams verify the requested item, document the quotation basis and plan international delivery without unsupported stock or lead-time claims.
Review the complete article number, suffix, label and required quantity.
State NEW condition, visible inspection scope and quotation basis in writing.
Review CPU support, output range and connected load.
Provide available product, connector and label views before shipment.
Use product-appropriate cushioning, moisture protection and export packaging.
Confirm carrier, freight cost, shipment tracking and customs documents.
Apply the one-year warranty under the written quotation and order terms.
Handle issues through documented review and return authorization.
Send 6ES7288-5AQ01-0AA0, the required quantity, destination country and available product label photos for quotation and compatibility review.
