Siemens 6ES7288-2QT16-0AA0 SIMATIC S7-200 SMART EM QT16 Transistor Output Module

Sixteen 24 V DC sourcing transistor outputs provide responsive switching for documented field loads in S7-200 SMART expansion systems.

Product Overview

Siemens 6ES7288-2QT16-0AA0 is the SIMATIC S7-200 SMART EM QT16 digital output expansion module. It adds sixteen sourcing transistor outputs for 24 V DC load circuits and does not add digital inputs. The module is suited to output expansion, maintenance replacement and control-panel projects that require semiconductor switching within the official electrical ratings. Before ordering, confirm the full article number, load voltage, steady-state and inrush current, output commons, external protection, suppression method, available expansion position and the controller project configuration.

Key Product Information

Detailed Technical Specifications

Signal and Load Path

Functions and Benefits

• Adds sixteen transistor outputs without introducing unused input channels.
• Sourcing semiconductor outputs support responsive 24 V DC switching.
• Channel status indication assists commissioning and fault isolation.
• Compact expansion width supports space-conscious control-panel layouts.
• Correct external protection and suppression help protect module and field circuits.

Applications

Installation, Wiring and Compatibility

Verify the output-common arrangement, 24 V DC load supply, polarity, per-channel current, group current and protective-device coordination before wiring. Apply suitable suppression to inductive loads and isolate power before installation or removal. Confirm the supported S7-200 SMART expansion position and update the controller project with the exact module configuration. Compare the original equipment label and terminal drawing before replacement.

Procurement Checklist

1. Match the complete order number: 6ES7288-2QT16-0AA0.
2. Confirm that sixteen transistor outputs are required and no inputs are expected.
3. Review the 24 V DC load type, current and inrush requirement.
4. Confirm controller compatibility, expansion layout and project configuration.
5. Request available-unit and product-label photos before shipment.

FAQ

Does 6ES7288-2QT16-0AA0 provide digital inputs?
No. The EM QT16 is configured as a sixteen-channel transistor output module.

What type of loads should be confirmed?
Confirm 24 V DC load current, inrush, polarity, switching frequency and suppression requirements.

How can compatibility be checked?
Send the CPU article number, expansion layout, project configuration and original module-label photo.

Can product and label photos be supplied?
Yes. Request available-unit photos and label details with the quotation.

Can this module be shipped internationally?
Worldwide shipping options are confirmed according to destination, shipment terms and current availability.

What warranty is provided?
The product is offered with a one-year warranty under the written quotation and order terms.
