Product Summary
Siemens 6ES7222-1HH32-0XB0 is a SIMATIC S7-1200 SM 1222 digital output module with sixteen relay outputs rated 2 A. It provides a higher-density relay switching option for control panels that must command compatible AC or DC loads through relay contacts. Typical procurement scenarios include maintenance replacement, machine refurbishment and planned S7-1200 I/O expansion. Before ordering, confirm the full suffix, CPU and STEP 7 project, load voltage, load category, inrush current, required switching frequency, connector and wiring arrangement, installation dimensions and original label details.
S7-1200 CPU→SM 1222→16 Outputs→relay / 2 A
Key Product Information
| Manufacturer |
Siemens |
| Complete Part Number |
6ES7222-1HH32-0XB0 |
| Product Type |
SM 1222 16-Channel 2 A Relay Digital Output Module |
| Series |
SIMATIC S7-1200, SM 1222 |
| Model Configuration |
SM 1222, DQ 16x relay/2 A |
| Product Condition |
NEW |
| Hardware Revision |
Contact us to confirm. |
| Firmware/Software Version |
Contact us to confirm. |
| Country of Origin |
GERMANY |
| Compatibility |
SIMATIC S7-1200 system; confirm the CPU, engineering project and module arrangement before ordering. |
| Warranty |
With 1 year warranty |
| Availability |
Contact us to confirm. |
| Shipping |
Worldwide shipping options are checked against the destination and written quotation. |
Technical Data Summary
| Output channels |
16 |
| Output technology |
Relay |
| Rated output current |
2 A |
| Series |
SIMATIC S7-1200 SM 1222 |
| Dimensions |
45 x 100 x 75 mm |
| Net weight |
0.237 kg |
| Detailed contact ratings |
Contact us to confirm. |
Functions and Integration
The module extends a compatible S7-1200 station with 16 relay outputs. Configure the exact module in the engineering project and verify field wiring before energization.
Installation Planning
Check the connector, conductor size, protective devices, load characteristics, mounting orientation, ventilation and available panel space against Siemens documentation.
Applications
- Relay switching in compatible S7-1200 machine-control panels.
- Maintenance replacement where the installed design requires relay contacts.
- Command of supported AC or DC loads after load-category verification.
- Panel expansion projects requiring higher contact-current capability.
Compatibility and Revision Notice
Confirm the complete part number and suffix, S7-1200 CPU and engineering project, total station arrangement, load voltage and interface, hardware revision, firmware or software version, front connector, installation dimensions, load type and original equipment label photographs. Please contact us to confirm the exact revision, firmware version, condition and availability before ordering.
FAQ
Is 6ES7222-1HH32-0XB0 currently available?
Availability is checked for the requested quantity and condition. Send the complete number 6ES7222-1HH32-0XB0 for a written supply confirmation.
What condition can 6ES7222-1HH32-0XB0 be supplied in?
The requested page condition is NEW. Product and label photographs can be checked before shipment when included in the quotation process.
How do I confirm compatibility?
Compare the complete suffix, output technology, channel count, load voltage, current, connector, CPU and STEP 7 project with the original installation.
Why is the complete suffix important?
The suffix identifies this exact SM 1222 configuration. A visually similar module may use a different channel count or output technology.
Can 6ES7222-1HH32-0XB0 be shipped internationally?
Worldwide shipping options can be checked after the destination country, quantity and packaging requirements are provided.
What warranty is provided?
This product is offered with 1 year warranty, subject to the written quotation terms and return authorization process.
Send us the complete part number, required quantity, destination country and product label photos. Our team will check availability, condition, compatibility requirements and shipping options.
Email: sales6@apterpower.com | WhatsApp: +86 18159889985
