Product Summary
Siemens 6ES7222-1BH32-0XB0 is a SIMATIC S7-1200 SM 1222 digital output module with sixteen 24 V DC transistor outputs rated 0.5 A. It expands the controller with higher output density for commands to compatible field devices in machine and process-control panels. The module is relevant to maintenance replacement, panel upgrades and controlled I/O expansion where the existing project requires transistor switching. Before purchase, confirm the complete order suffix, CPU and STEP 7 configuration, external protection, load voltage, channel current, wiring arrangement, front connector and installation dimensions.
S7-1200 CPU→SM 1222→16 Outputs→24 V DC transistor / 0.5 A
Key Product Information
| Manufacturer |
Siemens |
| Complete Part Number |
6ES7222-1BH32-0XB0 |
| Product Type |
SM 1222 16-Channel 24 V DC Transistor Digital Output Module |
| Series |
SIMATIC S7-1200, SM 1222 |
| Model Configuration |
SM 1222, DQ 16x24 V DC/0.5 A |
| Product Condition |
NEW |
| Hardware Revision |
Contact us to confirm. |
| Firmware/Software Version |
Contact us to confirm. |
| Country of Origin |
GERMANY |
| Compatibility |
SIMATIC S7-1200 system; confirm the CPU, engineering project and module arrangement before ordering. |
| Warranty |
With 1 year warranty |
| Availability |
Contact us to confirm. |
| Shipping |
Worldwide shipping options are checked against the destination and written quotation. |
Technical Data Summary
| Output channels |
16, individually grouped |
| Output technology |
Transistor |
| Permissible supply range |
20.4-28.8 V DC |
| Rated output current |
0.5 A per channel |
| Typical power loss |
2.5 W |
| Output delay |
50 microseconds on; 200 microseconds off |
| Short-circuit protection |
External protection required |
| Dimensions |
45 x 100 x 75 mm |
| Approximate weight |
220 g |
Functions and Integration
The module extends a compatible S7-1200 station with 16 24 V DC transistor outputs. Configure the exact module in the engineering project and verify field wiring before energization.
Installation Planning
Check the connector, conductor size, protective devices, load characteristics, mounting orientation, ventilation and available panel space against Siemens documentation.
Applications
- Digital command outputs in compatible S7-1200 machine-control panels.
- Maintenance replacement for installed transistor-output configurations.
- Control of verified 24 V DC field loads within the channel rating.
- Panel expansion requiring additional SM 1222 digital output points.
Compatibility and Revision Notice
Confirm the complete part number and suffix, S7-1200 CPU and engineering project, total station arrangement, load voltage and interface, hardware revision, firmware or software version, front connector, installation dimensions, load type and original equipment label photographs. Please contact us to confirm the exact revision, firmware version, condition and availability before ordering.
FAQ
Is 6ES7222-1BH32-0XB0 currently available?
Availability is checked for the requested quantity and condition. Send the complete number 6ES7222-1BH32-0XB0 for a written supply confirmation.
What condition can 6ES7222-1BH32-0XB0 be supplied in?
The requested page condition is NEW. Product and label photographs can be checked before shipment when included in the quotation process.
How do I confirm compatibility?
Compare the complete suffix, output technology, channel count, load voltage, current, connector, CPU and STEP 7 project with the original installation.
Why is the complete suffix important?
The suffix identifies this exact SM 1222 configuration. A visually similar module may use a different channel count or output technology.
Can 6ES7222-1BH32-0XB0 be shipped internationally?
Worldwide shipping options can be checked after the destination country, quantity and packaging requirements are provided.
What warranty is provided?
This product is offered with 1 year warranty, subject to the written quotation terms and return authorization process.
Send us the complete part number, required quantity, destination country and product label photos. Our team will check availability, condition, compatibility requirements and shipping options.
Email: sales6@apterpower.com | WhatsApp: +86 18159889985
