4 digital outputs; 24 V DC; up to 200 kHz
The Siemens 6ES7222-1BD30-0XB0 is an SB 1222 digital output signal board for SIMATIC S7-1200 controllers. Siemens specifies four 24 V DC digital outputs with operation up to 200 kHz. The board uses solid-state MOSFET outputs and is designed to extend a compatible CPU with compact high-speed switching capability. It suits pulse-oriented machine functions, small motion-support tasks and replacement of the same installed signal board. Before ordering, confirm the CPU model, output load, required switching frequency, wiring polarity, protection strategy, TIA Portal configuration and the complete article number shown on the existing unit.
| Manufacturer | Siemens |
|---|---|
| Complete Part Number | 6ES7222-1BD30-0XB0 |
| Product Type | SIMATIC S7-1200 SB 1222 High-Speed Digital Output Signal Board |
| Series | SIMATIC S7-1200 |
| Model Configuration | 4 digital outputs; 24 V DC; up to 200 kHz |
| Product Condition | NEW |
| Hardware Revision | Contact us to confirm |
| Firmware / Software Version | Contact us to confirm |
| Country of Origin | GERMANY |
| Compatibility | Confirm the exact CPU, system architecture and project configuration |
| Availability / Warranty | With 1 year warranty |
| Shipping | Worldwide shipping options available; terms confirmed in quotation |
Generate output states or pulse instructions in the S7-1200 CPU.
Drive four solid-state 24 V DC channels at the configured rate.
Use output status indication during commissioning and diagnosis.
Verify load current, polarity and external circuit protection before operation.
| Module designation | SB 1222 digital output signal board |
| Number of outputs | 4 digital outputs |
| Rated output voltage | 24 V DC |
| Maximum switching frequency | 200 kHz |
| Output technology | MOSFET solid-state outputs |
| Rated output current | 0.1 A per output |
| Status indication | Output status LEDs |
| Controller family | SIMATIC S7-1200 |
Confirm that the target S7-1200 CPU accepts this signal board and that each connected load remains within the board output rating. Review output polarity, external protection, cable length, grounding, switching frequency and the TIA Portal device configuration before energizing.
Siemens specifies four 24 V DC solid-state digital outputs with operation up to 200 kHz.
No. The official technical data identifies MOSFET solid-state outputs.
No. Verify load type, current demand, switching frequency, polarity and protection against the official limits.
Provide the CPU article number, hardware label, TIA Portal project and the existing signal board information.
Ask for current photos in the quotation so the article number and offered unit can be checked.
The offered unit can be quoted with a one-year warranty under the written quotation terms.
