SIMATIC S5 • 470-4 ANALOG OUTPUT
An isolated compact-design U analog output module with eight channels for voltage and current signals.
|
Siemens 6ES5470-4UC13 is a SIMATIC DP field-device interface that couples PROFIBUS DP to a non-intrinsically-safe PROFIBUS PA segment. It converts the DP transmission rate to the fixed PA rate while supplying the connected PA fieldbus. The specified output ranges are +1 to 5 V and +4 to 20 mA. Exact-order-code replacement is important for maintaining channel count, signal type, wiring and existing S5 system configuration. |
Procurement identity
6ES5470-4UC13 SIMATIC S5 Analog Output Module Origin: Germany |
| Complete order number | 6ES5470-4UC13 |
|---|---|
| Manufacturer | Siemens |
| Product type | SIMATIC S5 Analog Output Module |
| Lifecycle status | End Prod.Lifecycl. |
| Replacement status | Cancelled without replacement |
| Parameter | Official specification |
|---|---|
| Official designation | SIMATIC S5 analog output 470 |
| Article number | 6ES5470-4UC13 |
| Mechanical design | Isolated compact design U |
| Number of outputs | 8 |
| Voltage output range | +1 to 5 V |
| Current output range | +4 to 20 mA |
| Automation system | SIMATIC S5 |
| Lifecycle | End Prod.Lifecycl. |
| Replacement status | Product cancelled without replacement |
| Packaging dimensions (L × W × H) | 26.7 × 21.3 × 3.5 cm |
| Net weight | 0.743 kg |
| Country of origin | Germany |
| Use case | Role in the system |
|---|---|
| Eight-channel analog control | Provides eight isolated analog outputs in a SIMATIC S5 control system. |
| Voltage signal output | Supports the specified +1 to 5 V range for compatible field devices. |
| Current signal output | Supports the specified +4 to 20 mA range for compatible process loops. |
| 01 | Confirm the complete 6ES5470-4UC13 article number and module revision. |
| 02 | Record all eight channel assignments and configured signal ranges. |
| 03 | Verify each connected device expects +1 to 5 V or +4 to 20 mA. |
| 04 | Document connector wiring, common references and shielding. |
| 05 | Inspect the front connector, backplane interface and housing condition. |
| 06 | Evaluate successor Cancelled without replacement as a separate migration project. |
Siemens specifies +1 to 5 V and +4 to 20 mA outputs across eight isolated channels.
No. The official detailed description identifies it as SIMATIC S5 analog output 470 with eight outputs.
Siemens identifies Cancelled without replacement as the successor, but wiring, mounting, termination and project requirements must be checked separately.
Send the complete order code, quantity, condition preference, delivery destination and clear product photographs for a supply review.
Copy or open: sales6@apterpower.com | +86 181 5988 9985
FIELD DEVICE PROCUREMENT SUPPORT
A procurement-focused review of module identity, eight-channel assignments, signal ranges, wiring, condition evidence, packing and delivery.
Label RecordComplete order code, revision and serial evidence. |
Channel RecordFront connector, terminal numbering and wiring photographs. |
Condition RecordHousing, backplane interface and connector condition. |
| Stage | Review item | Procurement outcome |
|---|---|---|
| 01 · Identify | Order label, module revision and serial markings | Establishes the exact 470-4 output-module variant |
| 02 · Map | Eight channel assignments and configured ranges | Records the installed analog-output application |
| 03 · Verify | Voltage or current requirement for every channel | Checks signal-range alignment |
| 04 · Inspect | Front connector, backplane and housing | Provides condition evidence before supply |
| 05 · Protect | Connector protection, anti-static wrap and rigid packing | Reduces handling and transport risk |
| 06 · Deliver | Quantity, destination, warranty terms and shipment method | Defines the quotation and fulfilment scope |
| 1 | Complete order code: 6ES5470-4UC13 |
| 2 | Front and side label photographs with revision details |
| 3 | Eight-channel assignment and signal-range list |
| 4 | Front-connector wiring and terminal photographs |
| 5 | S5 rack and backplane configuration information |
| 6 | Quantity, condition preference, destination and required date |
| Packing | Connector protection, anti-static wrapping and reinforced outer packing |
|---|---|
| Condition evidence | Label and physical-condition images retained with the supply record |
| Delivery | Trackable international shipment to the confirmed destination |
| Warranty | Terms stated in the quotation for the specific offered item |
Send the complete order code, quantity, condition preference, delivery destination and clear product photographs for a supply review.
Copy or open: sales6@apterpower.com | +86 181 5988 9985
