HIMA HIMatrix F60AO801 is a safety-related analog output module for HIMatrix F60 systems, delivering reliable signal control with SIL-rated performance for critical industrial automation and process safety applications.

Specifications

General

• Manufacturer: HIMA
• Model: HIMatrix F60AO801
• Product Type: Analog Output Module (Safety-related)
• System: HIMatrix F60 modular safety controller

Output Characteristics

• Output Channels: Typically 8 analog outputs
• Signal Types: 4–20 mA / 0–10 V (configurable)
• Resolution: High-resolution DAC (industrial grade)
• Accuracy: Approx. ±0.1% full scale

Electrical

• Supply Voltage: 24 V DC (approx. 19.2–28.8 V)
• Power Consumption: ~5 W max

Safety & Performance

• Safety Integrity Level: SIL 3 (IEC 61508 compliant)
• Diagnostics: Built-in self-monitoring and fault detection
• Operating Principle: De-energize-to-trip / energize-to-trip

Environmental

• Operating Temperature: -25°C to +70°C
• Storage Temperature: -40°C to +85°C
• Humidity: 5–95% non-condensing

System Features

• Integration: HIMatrix modular PES (F60 platform)
• Communication: SafeEthernet, Modbus TCP (via system CPU)

Application

• Process Industry Control
  Used in oil & gas, chemical plants, and pipelines for precise analog signal output control.
• Fire & Gas Safety Systems
  Ensures accurate actuator response in emergency shutdown and safety loops.
• Burner Management Systems (BMS)
  Supports reliable control of combustion processes in industrial boilers.
• Turbine & Energy Systems
  Provides stable analog outputs for turbine monitoring and control environments.

• Machine & Logistics Safety
  Applied in conveyors, cranes, and automated systems requiring SIL-rated control outputs.
