IC200ALG230 Overview

The General Electric IC200ALG230 Analog input 12 bit voltage/current 4 channel is a 4-channel analog input module, supporting both voltage and current signals. It operates with backplane power and provides 4 words of input data to the host CPU or NIU for processing.

Features and Benefits

• Versatile Inputs: Adapts to 4 voltage or 4 current input signals for flexible system integration.

• High Precision: Provides 12-bit resolution, ensuring accurate measurement of analog process variables.

• Simplified Design: Features single-ended channels with a shared common return to reduce wiring complexity and errors.

• Power Efficiency: Powered directly from the backplane, eliminating the need for an external module power supply.

FAQ

Q: What types of signals does the IC200ALG230 module accept?

A: It accepts either 4 voltage inputs or 4 current inputs, but not both simultaneously.

Q: What is the resolution of this analog input module?

A: The module provides 12-bit resolution for accurate analog signal conversion.

Q: Does this module require external power to operate?

A: No, it receives power directly from the backplane and doesn't need an external power source.

Q: How many data words does this module provide to the controller?

A: It provides 4 words of analog input data to the CPU or NIU.

Q: What is the channel configuration of this module?

A: It features 4 single-ended channels that all share a common return.
