A5E00714562 FS450R12KE3-S1 Overview

The Siemens A5E00714562 INVERTER DRIVER BOARD is a robust IGD2/R4 inverter driver board, capable of handling high currents up to 450A and DC link voltages from 500-1200V for reliable industrial automation.

Technical Data Summary: Siemens A5E02822120

Part Type: Rectifier Trigger Board (TDB).

Manufacturer: Produced by Siemens Robicon.

Application: Controls converter modules in industrial power systems.

Key Specification: Operates on 24V DC input (±10%), with a typical amplitude of 15-30V DC.

Environmental: Operating temperature range is 0°C to 55°C.

Physical: Lightweight at 0.22 kg, compact for integration.

FAQ

Q1: What is the Siemens A5E00714562 FS450R12KE3-S1?

A1: It is a high-power IGD2/R4 inverter driver board, also known as a Powerblock Unit.

Q2: What is its key electrical specification?

A2: It handles a DC link input of 500-1200V and a nominal output current of 450A.

Q3: How is the unit cooled?

A3: It uses a passive and efficient natural convection cooling system.

Q4: What communication interface does it support?

A4: It is equipped with a Profinet interface for seamless industrial network integration.

Q5: What protection does it offer for the operating environment?

A5: It has an IP20 protection class, guarding against dust and light water splashes.
