Siemens 6GK5778-1GY00-0AA0 is a SCALANCE W778-1 M12 industrial wireless LAN access point for 2.4 and 5 GHz networks. The unit uses one integrated radio, supports IEEE 802.11a/b/g/h/n, and provides a gross wireless rate up to 300 Mbit/s. Two D-coded M12 Industrial Ethernet ports form an integrated two-port switch with PoE support, while redundant 24 V DC connections use A-coded M12 interfaces. The IP65 enclosure and documented -20 to +60 °C operating range suit protected industrial locations. Procurement checks should cover the exact suffix, national radio approvals, antenna selection, firmware, KEY-PLUG functions, power method, connectors, and label photographs.
| Product Condition | Original new |
| Availability | In stock |
| Official Lifecycle | PM300: Active Product |
| Warranty | With 1 year warranty |
| Shipping | Worldwide shipping options available |
Condition, availability and warranty are Stockoems commercial information, not manufacturer commitments.
| Manufacturer | Siemens |
| Complete Part Number | 6GK5778-1GY00-0AA0 |
| Product Type | SCALANCE W778-1 M12 IWLAN Access Point |
| Product Family | SCALANCE W778-1 M12 for indoor use |
| Installed Radio | 1 |
| Wireless Standards | IEEE 802.11a/b/g/h/n |
| Frequency Bands | 2.4 GHz and 5 GHz |
| Maximum Gross WLAN Rate | 300 Mbit/s |
| Industrial Ethernet | 2 × M12, D-coded, 10/100 Mbit/s; PoE integrated two-port switch |
| External Antenna Connections | 2 × N-Connect sockets |
| Power Supply | Redundant 24 V DC via A-coded M12; PoE supported |
| Configuration Media | C-PLUG and KEY-PLUG supported |
| Wireless Features | WPA2 / IEEE 802.11i; IEEE 802.11e support |
| Degree of Protection | IP65 |
| Operating Temperature | -20 to +60 °C |
| Net Weight | 0.600 kg |
| Country of Origin | GERMANY |
| Use Area | Application Guidance |
|---|---|
| Industrial WLAN cells | Wireless access for compatible industrial clients connected to a verified wired Ethernet network. |
| Mobile automation equipment | Connectivity for supported mobile terminals or moving equipment after radio planning and approval checks. |
| IP65 indoor installations | Industrial indoor mounting where enclosure protection, temperature, power, and antenna placement meet the project requirements. |
| Installed-base maintenance | Replacement after confirming the exact suffix, firmware, national approvals, antenna system, KEY-PLUG, M12 wiring, and network configuration. |
Siemens lists this exact order code as PM300: Active Product. Procurement should still verify national radio approvals, firmware, antenna configuration, power method, security settings, KEY-PLUG use, and the complete product label before installation.
Send us the complete part number, required quantity, destination country and product label photos. Our team will check availability, condition, compatibility requirements and shipping options.
Email: sales6@apterpower.com | WhatsApp: +86 18159889985
Structured verification, inspection, packaging, documentation and after-sales coordination for 6GK5778-1GY00-0AA0 procurement.
Model, suffix and label identity
Condition and technical compatibility
Product, connectors and packaging
Worldwide shipping and documentation
Warranty, returns and after-sales
| Service Item | How It Supports Your Purchase |
|---|---|
| Model and suffix verification | The quoted order code is compared with the request and readable label evidence. |
| Condition confirmation | Commercial condition is stated in writing and supported with available inspection evidence. |
| Technical compatibility review | Interfaces, power, antennas, firmware, approvals and network requirements are reviewed against the information supplied by the buyer. |
| Product and label photo confirmation | Clear product, connector, nameplate and packaging photographs can be requested before shipment. |
| Protective packaging | The unit is prepared with suitable protection for connectors, enclosure surfaces and transit handling. |
| Worldwide shipping | Available shipping options are coordinated for the destination country without promising an unconfirmed delivery date. |
| Shipment tracking | Tracking details are supplied when issued by the selected carrier. |
| Customs documentation | Commercial shipping documents are prepared according to the confirmed transaction and destination requirements. |
| Written warranty terms | The applicable Stockoems warranty terms are stated in writing before order confirmation. |
| Return authorization process | Return requests follow a documented review and authorization process. |
| After-sales response | Post-delivery questions are coordinated with the sales and technical support team. |
Complete part number, suffix, label details and requested configuration are checked before order confirmation.
Available product, connector, label and packaging photographs support condition and identity review.
Protective packaging, carrier coordination, shipment tracking and customs documentation are handled as confirmed.
Share the complete model, required quantity, destination country and available product label photos for a documented review.
Email: sales6@apterpower.com | WhatsApp: +86 18159889985
