Siemens 6GK5774-1FX00-0AB0 · Dual-band industrial WLAN · 2-port RJ45 switch · PoE
Siemens 6GK5774-1FX00-0AB0 is a SCALANCE W774-1 RJ45 industrial WLAN access point for control-cabinet network applications. The exact variant provides one radio, two R-SMA antenna ports, IEEE 802.11a/b/g/h/n support and operation in the 2.4 GHz and 5 GHz bands with a gross data rate up to 300 Mbit/s. Two RJ45 Ethernet ports form an integrated 100 Mbit/s switch, with PoE and redundant 24 V DC supply options. Before procurement, confirm national radio approvals, antenna selection, KEY-PLUG requirements, security configuration, cabinet temperature, power method and the complete -0AB0 suffix.
| Product Condition | Original new |
| Availability | In stock |
| Official Lifecycle | Active Product |
| Warranty | With 1 year warranty |
| Shipping | Worldwide shipping options available |
Condition, availability and warranty are Stockoems commercial information, not manufacturer commitments.
| Manufacturer | Siemens |
| Complete Part Number | 6GK5774-1FX00-0AB0 |
| Product Type | SCALANCE W774-1 RJ45 IWLAN access point |
| Wireless Radios | 1 |
| Antenna Ports | 2 × R-SMA |
| Wireless Standards | IEEE 802.11a/b/g/h/n |
| Frequency Bands | 2.4 GHz and 5 GHz |
| Gross Wireless Data Rate | Up to 300 Mbit/s |
| Ethernet Interfaces | 2 × RJ45, maximum 100 Mbit/s |
| Integrated Switch | 2 ports |
| Power Options | PoE and redundant 24 V DC |
| Security | WPA2 / IEEE 802.11i/e |
| iFeatures | Supported via KEY-PLUG |
| Protection Class | IP30 |
| Operating Temperature | -20 to 60 °C |
| Net Weight | 0.621 kg |
| Country of Origin | Germany |
| Network Fit | Industrial Wireless LAN installations using SCALANCE W access points and cabinet-mounted Ethernet equipment |
| Typical Applications | Wireless connectivity for automation cells, mobile equipment, controller and HMI communication |
| Maintenance Use | Replacement of the exact W774-1 RJ45 variant after radio approval and configuration review |
| Configuration Focus | Country approval, WLAN channel plan, antenna system, security profile, KEY-PLUG, PoE or 24 V supply |
This exact order code should not be treated as universally interchangeable with a similar series model. Before purchase or replacement, verify:
The official description requires observance of national approvals. Confirm the destination country, certification label, antenna arrangement, PoE class, redundant 24 V wiring and wireless security settings before replacing an installed access point.
Siemens SiePortal lists the exact 6GK5774-1FX00-0AB0 order code as Active Product. This wording applies only to the complete -0AB0 variant reviewed here.
It identifies the exact SCALANCE W774-1 RJ45 variant reviewed on Siemens SiePortal; regional approval and label details must match the destination.
The official description lists IEEE 802.11a/b/g/h/n for 2.4 GHz and 5 GHz operation.
The device has two RJ45 Ethernet ports and two R-SMA antenna ports.
Siemens SiePortal lists this exact order code as Active Product.
Review country approvals, antennas, KEY-PLUG use, security settings, PoE or 24 V supply, firmware and network parameters.
Yes. Request photographs of the complete enclosure, certification label, R-SMA connectors, RJ45 ports, terminal block and packaging.
Send us the complete part number, required quantity, destination country and product label photos. Our team will check availability, condition, compatibility requirements and shipping options.
Stockoems supports industrial spare-parts purchasing with a practical review process covering order-code identity, installed-system context, visible condition and export handling. For 6GK5774-1FX00-0AB0, buyers can provide label photos, cabinet information and project requirements so our team can organize a clearer compatibility and condition review before dispatch.
A useful procurement check goes beyond matching a short model name. Our team reviews the complete suffix, visible hardware features, connector arrangement and the buyer’s installation notes. The following workplace photographs show three different activities used during this process: reading the unit label, comparing cabinet wiring with technical documentation, and jointly checking module information before commercial confirmation.
| Review Area | Procurement Value |
|---|---|
| Complete Model Identity | Full order codes and suffixes are compared to reduce the risk of receiving a similar but incompatible configuration. |
| Installed-System Context | Hardware, firmware, software, operator-panel and field-connection details can be included in the pre-order review. |
| Visible Condition Evidence | Photos can document the enclosure, label, ports, accessories, packaging and other visible features of an available unit. |
| Clear Order Coordination | Quantity, destination, inspection requests, warranty scope and delivery options are consolidated before shipment. |
| Protective Export Handling | Packing is selected with sensitive industrial electronics and the planned international route in mind. |
Provide the exact part number, quantity, destination and installed-system details.
Labels, connectors, physical condition and requested technical checkpoints are examined.
Availability, inspection scope, warranty and shipping choices are organized for approval.
The unit is prepared for the chosen route with supporting shipment documentation.
For the strongest compatibility review, send clear photographs of the installed nameplate, adjacent connectors and cabinet position together with any available STEP 7 project or maintenance record details.
