Eight-channel PROFIsafe digital output module for safety-related actuator control
Siemens 6ES7526-2BF00-0AB0 is a fail-safe digital output module for SIMATIC S7-1500 central systems and ET 200MP distributed I/O. It provides eight 24 V DC outputs rated up to 2 A and uses PROFIsafe communication for safety-related actuator control. The module supports configurable PP or PM switching and is designed for applications up to SIL 3 and PL e when correctly engineered within an approved safety system. Procurement checks should confirm the full order code, front connector, firmware, TIA Portal project version, F-addressing, power supply, wiring, safety parameters and the installed CPU or interface module before replacement.
| Product Condition | Original new |
|---|---|
| Availability | In stock |
| Official Lifecycle | PM300: Active Product |
| Warranty | With 1 year warranty |
| Shipping | Worldwide shipping options available |
Condition, availability and warranty are Stockoems commercial information, not manufacturer commitments.
| Manufacturer | Siemens |
|---|---|
| Complete Part Number | 6ES7526-2BF00-0AB0 |
| Product Type | Fail-safe digital output module |
| Product Family | SIMATIC S7-1500 / ET 200MP F-I/O |
| Product Type Designation | F-DQ 8x24VDC/2A PPM |
| Number of Digital Outputs | 8 |
| Rated Supply Voltage | 24 V DC |
| Permissible Supply Range | 19.2 to 28.8 V DC |
| Output Current | Up to 2 A per channel |
| Switching Method | PP or PM switching, parameterizable |
| Safety Communication | PROFIsafe |
| Safety Level | Up to SIL 3 / PL e |
| Engineering | TIA Portal V13 SP1 with HSP 0086 or later |
| Module Width | 35 mm |
| Net Weight | 0.373 kg |
| Country of Origin | Germany |
| Applicable System | SIMATIC S7-1500 F-CPU central configuration or ET 200MP distributed I/O |
|---|---|
| System Role | Fail-safe switching of 24 V DC actuators through PROFIsafe |
| Typical Applications | Machine safety, process interlocks, safe valves, contactors and shutdown circuits |
| Replacement Focus | F-address, safety signature, firmware, wiring, front connector and project configuration |
A matching enclosure or partial order number does not confirm compatibility. Compare project records and product-label evidence before replacement.
Siemens lists 6ES7526-2BF00-0AB0 as PM300: Active Product. This status must not be interpreted as discontinued. Replacement planning should still verify firmware, TIA Portal configuration, PROFIsafe addressing, front connector, wiring and the validated safety project.
It identifies the Siemens ET 200MP F-DQ 8x24VDC/2A PPM fail-safe digital output module.
The module provides eight fail-safe 24 V DC digital outputs rated up to 2 A per channel.
The module communicates with fail-safe SIMATIC CPUs through PROFIsafe.
Check the complete order code, firmware, F-address, TIA Portal project, output wiring, front connector and safety parameters.
Siemens lists this exact model as PM300: Active Product.
Available product, label and packaging photographs can be reviewed during order verification.
Send us the complete part number, required quantity, destination country and product label photos. Our team will check availability, condition, compatibility requirements and shipping options.
Email: sales6@apterpower.com
WhatsApp: +86 18159889985
Structured verification, inspection, documentation and delivery support for Siemens 6ES7526-2BF00-0AB0.
| Model and suffix verification | The complete order code and suffix are checked against the inquiry, label evidence and supporting records. |
|---|---|
| Condition confirmation | Visible condition, packaging status and supplied accessories are reviewed before shipment. |
| Technical compatibility review | Engineers compare system fit, interfaces, electrical requirements and project documentation. |
| Product and label photo confirmation | Available product, nameplate and packaging photographs can be reviewed for order-code and condition checks. |
| Protective packaging | The unit is prepared with suitable protective materials to reduce handling and transit risk. |
| Worldwide shipping | International shipping options are coordinated according to destination and order requirements. |
| Shipment tracking | Tracking information is provided when issued by the selected carrier. |
| Customs documentation | Commercial and shipping documents are prepared for the agreed delivery arrangement. |
| Written warranty terms | Applicable Stockoems warranty scope and terms are documented with the commercial offer. |
| Return authorization process | Return requests are reviewed through a documented authorization process and agreed conditions. |
| After-sales response | Our team supports order-document, shipment and product-identification questions after delivery. |
Confirm the full order code, eight-channel F-DQ configuration, 24 V DC supply, 2 A channel rating, PROFIsafe address, PP or PM switching, front connector, firmware and validated safety project. Similar housings or partial model numbers do not establish compatibility.
Look for consistent model identification, clear condition statements, traceable commercial documents, product-label evidence, written warranty terms and a defined return process.
Review the quotation, complete order code, manufacturer label, condition photographs, packing information, warranty scope, shipping terms, customs documents and return authorization conditions.
Match 6ES7526-2BF00-0AB0 in full and compare firmware, interfaces, electrical requirements, wiring and project records with the installed system.
Warning signs include incomplete model numbers, refusal to provide nameplate evidence, conflicting technical statements, unclear condition descriptions and an undefined return process.
