SIMATIC S7-300 • CPU 315-2 DP
A 24 VDC central processing unit with 64 KB work memory and a DP master/slave interface.
|
Siemens 6ES7315-2AF03-0AB0 is a SIMATIC DP field-device interface that couples PROFIBUS DP to a non-intrinsically-safe PROFIBUS PA segment. It converts the DP transmission rate to the fixed PA rate while supplying the connected PA fieldbus. Its second interface operates as a PROFIBUS DP master or slave. Replacement planning must match the exact hardware order code, rack configuration, distributed-I/O network and archived STEP 7 project. |
Procurement identity
6ES7315-2AF03-0AB0 SIMATIC S7-300 CPU 315-2 DP Origin: Germany |
| Complete order number | 6ES7315-2AF03-0AB0 |
|---|---|
| Manufacturer | Siemens |
| Product type | SIMATIC S7-300 CPU 315-2 DP |
| Lifecycle status | PM500: Discontinued Product or end of PLM & Support |
| Replacement status | Deleted without replacement |
| Parameter | Official specification |
|---|---|
| Official designation | SIMATIC S7-300 CPU 315-2 DP central processing unit |
| Article number | 6ES7315-2AF03-0AB0 |
| Integrated power supply | 24 VDC |
| Work memory | 64 KB |
| Second interface | PROFIBUS DP master/slave |
| Automation system | SIMATIC S7-300 |
| Lifecycle | PM500: Discontinued Product or end of PLM & Support |
| Lifecycle effective date | End of product lifecycle since 01 October 2022 |
| Replacement status | Product deleted without replacement |
| Packaging dimensions (L × W × H) | 15.1 × 13.2 × 9.1 cm |
| Net weight | 0.524 kg |
| Country of origin | Germany |
| RoHS status | Product is not RoHS-compliant |
| Use case | Role in the system |
|---|---|
| S7-300 central control | Executes the installed automation program with 64 KB work memory. |
| PROFIBUS DP coordination | Operates the second interface as DP master or slave for compatible distributed I/O. |
| Installed-base maintenance | Supports exact-model service when rack, project, network and hardware revisions are preserved. |
| 01 | Confirm the complete 6ES7315-2AF03-0AB0 article number and hardware revision. |
| 02 | Verify the archived STEP 7 project and CPU configuration before exchange. |
| 03 | Record the rack, power supply, signal modules and communication modules. |
| 04 | Document the PROFIBUS DP topology, station addresses and termination. |
| 05 | Confirm 24 VDC supply wiring and grounding before installation. |
| 06 | Evaluate successor Deleted without replacement as a separate migration project. |
Siemens specifies 64 KB work memory, integrated 24 VDC supply and a second PROFIBUS DP master/slave interface.
The complete order code, hardware revision, STEP 7 project and connected I/O configuration must be checked first.
Siemens identifies Deleted without replacement as the successor, but wiring, mounting, termination and project requirements must be checked separately.
Send the complete order code, quantity, condition preference, delivery destination and clear product photographs for a supply review.
Copy or open: sales6@apterpower.com | +86 181 5988 9985
