Four-channel isolated current input module with HART communication for high-availability process instrumentation.
Siemens 6DL1134-6UD00-0PK0 is a SIMATIC ET 200SP HA analog input module providing four isolated current inputs for 2-wire and 4-wire transmitters. Each channel supports HART communication, channel diagnostics and 16-bit conversion for process values in demanding plant environments.
The exact module is configured for terminal block type K0 or L0 and carries color code CC01. Replacement planning must match the complete order number, terminal block, field transmitter supply arrangement and engineering configuration rather than relying only on the ET 200SP HA family name.
| Field | Verified information |
|---|---|
| Manufacturer | Siemens |
| Complete part number | 6DL1134-6UD00-0PK0 |
| Product lifecycle | PM300: Active Product |
| PLM effective date | No phase-out date stated |
| Official designation | AI 4xI 2-/4-wire HART isolated |
| Country of origin | Germany |
| Technical characteristic | Specification |
|---|---|
| System / module | SIMATIC ET 200SP HA analog input module |
| Input channels | 4 current inputs, electrically isolated |
| Transmitter connection | 2-wire and 4-wire current transmitters |
| Measuring ranges | 0 to 10 mA; 0 to 20 mA; 4 to 20 mA; HART |
| HART communication | 4 integrated HART modems, one per channel |
| Resolution | 16 bit |
| Accuracy | ±0.1% |
| Diagnostics | Channel diagnostics supported |
| Terminal block requirement | Type K0 or L0 |
| Color code | CC01 |
| Operating temperature | -40 to +70 °C |
| Dimensions (W × H × D) | 22.5 × 115 × 138 mm |
| Siemens Mall net weight | 0.150 kg |
| Country of origin | Germany |
Connects isolated 2-wire and 4-wire current transmitters in process plants.
Combines analog measurement with digital HART communication for compatible field instruments.
Fits ET 200SP HA architectures requiring channel diagnostics and robust environmental capability.
Siemens lists 6DL1134-6UD00-0PK0 as PM300: Active Product. No phase-out date is stated in the exact current Siemens product listing. Procurement should still verify the full order number, terminal block type, module firmware, HART field-device configuration and installed ET 200SP HA engineering project.
It is a four-channel isolated HART analog input module for SIMATIC ET 200SP HA.
The module provides four current input channels.
Yes. Siemens specifies four integrated HART modems, one for each channel.
The official product data specifies terminal block type K0 or L0.
Siemens lists the exact order number as PM300: Active Product.
Confirm the full part number, terminal block, color code, current ranges, HART configuration, firmware and engineering project.
