SIMATIC HMI OPERATOR PANEL
Key-operated HMI with 5.7-inch STN color display
Siemens 6AV6542-0CA10-0AX0 is a SIMATIC OP 270 6-inch operator panel with a 5.7-inch STN color display and 2 MB of configuration memory. The exact-model Siemens data sheet identifies a keypad-based Windows CE panel configurable with ProTool from Version V6.0. It provides serial interfaces, a USB interface and a CompactFlash slot for legacy machine visualization and operator control. Replacement planning must address the existing ProTool project, communication wiring, cutout and power supply.
| Commercial item | Procurement statement |
|---|---|
| Condition | Original new industrial product, subject to exact-label and configuration verification |
| Availability | Stock and supply verification before quotation |
| Warranty | One-year warranty, subject to written quotation terms |
| Verified item | Official Siemens data |
|---|---|
| Manufacturer | Siemens |
| Complete article number | 6AV6542-0CA10-0AX0 |
| Product family | SIMATIC OP 270 |
| Product type | Key-operated HMI panel |
| Display | 5.7-inch STN color |
| Resolution | 320 x 240 pixels |
| Configuration memory | 2 MB user data |
| Engineering software | ProTool from Version V6.0 |
| Interfaces | 2 x RS232, 1 x RS422, 1 x RS485, 1 x USB, 1 x CF slot |
| Protection | IP65 front; IP20 rear |
The OP 270 serves as a local machine interface for process displays, status messages, alarms and operator commands. It is used in legacy automation systems whose HMI project and serial communication architecture were engineered for the OP 270 platform.
A replacement panel must be evaluated against the archived ProTool project, configured drivers, serial pinout, screen layout, memory use, panel cutout and 24 V DC supply. Similar-looking panels are not assumed interchangeable.
The consulted exact-model Siemens data sheet confirms the 6AV6542-0CA10-0AX0 hardware and software details but does not state a lifecycle category. No lifecycle label is inferred; exact-article support and spare-part status should be confirmed with Siemens during procurement.
It is a SIMATIC OP 270 keypad operator panel with a 5.7-inch STN color display.
Siemens specifies configuration with ProTool from Version V6.0.
The exact-model data sheet lists serial and USB interfaces and states that Ethernet is not provided.
No direct substitution is assumed; suffix, hardware, project and interface compatibility must be reviewed.
No lifecycle category is stated in that document, so none is inferred here.
Send the exact order code, installed system details, quantity and destination for availability and compatibility review.
