016-80686-0 Overview

The PARKER 016-80686-0 Remote Relief Valve is a direct-operated, seated pressure relief valve for remote hydraulic control. It features multiple mounting styles and pressure ranges up to 350 Bar with reliable operation.

Technical Data Summary

Operation Type: Direct-operated, seated pressure relief valve for remote control applications .

Maximum Pressure: Rated for up to 350 Bar (5075 PSI) at port P .

Flow Capacity: Supports a nominal flow of 3.8 LPM (1.0 GPM) .

Connection Size: Features a G1/4" connection interface .

Fluid Compatibility: Designed for hydraulic oil per DIN 51524 with NBR seals .

Temperature Range: Operates in ambient and fluid temperatures from -20°C to +70°C .

FAQ

Q1: What type of valve is the Parker 016-80686-0?

A1: It is a direct-operated, seated pressure relief valve from the R1E02 series.

Q2: What are the available pressure ranges for this valve?

A2: The available pressure ranges are 105 Bar (1523 PSI), 210 Bar (3045 PSI), and 350 Bar (5075 PSI).

Q3: What mounting options are available for this valve?

A3: It offers three body variants: foot mounting, front panel mounting, and subplate mounting.

Q4: What is the nominal flow capacity of this valve?

A4: The nominal flow capacity is 3.8 LPM (1.0 GPM).

Q5: What is the maximum operating pressure at port P?

A5: The maximum operating pressure at port P is 350 Bar (5075 PSI), while port T must remain depressurized.
