Bently Nevada 9200-03-02-02-00 is a two-wire moving-coil Seismoprobe velocity transducer configured for absolute bearing-housing, casing and structural vibration measurement. The complete official order code specifies a 90-degree mounting orientation with ±2.5-degree tolerance, 4.5 Hz minimum operating frequency, side-mounted connector, circular base with a 1/4-28 UNF stud and no agency approval option. It provides a self-generated voltage proportional to vibration velocity without external excitation. Procurement teams should verify the 90-degree calibration, mounting stud, connector direction, cable and monitor termination, polarity, environmental limits, approval requirements and label photographs before treating it as interchangeable with another 9200 configuration.
| Product Condition | Original new |
| Availability | In stock |
| Warranty | With 1 year warranty |
| Shipping | Worldwide shipping options available |
Condition, availability and warranty are Stockoems commercial information, not manufacturer commitments.
| Manufacturer | Bently Nevada, a Baker Hughes business |
| Complete Part Number | 9200-03-02-02-00 |
| Product Type | Two-wire Seismoprobe velocity transducer |
| Measurement | Absolute bearing-housing, casing or structural vibration |
| Technology | Moving-coil, self-powered two-wire transducer |
| Mounting Angle Option | 90° ±2.5° |
| Minimum Operating Frequency | 4.5 Hz (270 cpm) |
| Connector/Cable Option | Side mount, no integral cable |
| Mounting Base | Circular base with 1/4-28 UNF stud |
| Agency Approval Option | No approvals |
| Sensitivity | 20 mV/mm/s (500 mV/in/s), ±5% |
| Frequency Response | 4.5 Hz to 1 kHz, +0/-3 dB typical |
| Operating and Storage Temperature | -29°C to +121°C (-20°F to +250°F) |
| Dynamic Operating Range | 2.54 mm (0.100 in) peak-to-peak maximum displacement |
| Coil Resistance | 1.25 kΩ ±5% |
| Typical Weight | 300 g (10.5 oz) |
| Country of Origin | USA |
The 90-degree orientation is part of the calibrated order configuration and must be preserved during replacement.
| System Fit | Continuous or periodic velocity measurement with compatible machinery monitoring or diagnostic instruments. |
| Typical Applications | Absolute bearing-housing, casing and structural vibration where the calibrated orientation is 90 degrees. |
| Maintenance Use | Replacement where angle, frequency response, connector, mounting stud and electrical termination match. |
The current official 9200 and 74712 datasheet confirms this complete 9200 configuration but does not provide a lifecycle term for 9200-03-02-02-00. This page therefore does not classify the transducer as Active, Obsolete or Discontinued.
It specifies a 90-degree mounting orientation with ±2.5-degree tolerance and a 4.5 Hz minimum operating frequency.
The calibrated mounting orientation is different; the complete suffix must match the installed measurement point.
This model uses a side-mounted connector and circular base with a 1/4-28 UNF stud.
No. The moving-coil transducer produces a voltage output directly proportional to vibration velocity.
No explicit lifecycle term for this complete order code was confirmed in current official documentation.
Yes. Request clear views of the label, calibrated orientation, mounting stud, connector and packaging.
