The 130539-12 Bently Nevada 3-Conductor Shielded Cable is a 3-conductor shielded cable with 18AWG wire. It features a 3-socket plug with fluorosilicone boot and terminal lugs, available in lengths from 0.6m to 30m.

Features and benefits

3-Conductor Design: Shielded 18AWG (1.0 mm²) cable for reliable signal transmission

Dual-End Termination: 3-socket plug with fluorosilicone elastomer boot at one end, terminal lugs at the other

Flexible Length: Available from 2.0 ft (0.6 m) to 99 ft (30 m) for versatile installation

Environmental Protection: Fluorosilicone boot provides resistance to harsh conditions

System Compatibility: Works with 3300 XL 8 mm Proximity Transducer System components

Reliable Connection: Ensures secure interface between probe and monitoring equipment

FAQ

Q1: What is the primary application for these accelerometers?

A1: They are intended for critical machinery applications requiring casing acceleration measurements, such as gear mesh monitoring.

Q2: What are the key specifications of the 330400 model?

A2: The 330400 provides an amplitude range of 50 g peak and a sensitivity of 100 mV/g.

Q3: How does the 330425 model differ from the 330400?

A3: The 330425 has a larger amplitude range of 75 g peak with a sensitivity of 25 mV/g.

Q4: What industry standard are these accelerometers designed to meet?

A4: They are designed to address the requirements of the American Petroleum Institute Standard 670 for accelerometers.

Q5: Where should these accelerometers be installed for effective measurement?

A5: They must be installed on the bearing housing or machine casing to accurately transmit rotor vibration.
