PM3328B-6-1-3-E 80026-524-01 Product datasheet

PM3328B-6-1-3-E 80026-524-01 Functional Description

The PM3328B-6-1-3-E 80026-524-01 Allen Bradley Power Supply represents a specialized power supply solution engineered specifically for PowerFlex 7000 series AC drive systems. This industrial-grade unit delivers 1500-watt power capacity with single-phase input compatibility, supporting wide voltage ranges from 100 to 240V AC at 50/60Hz frequency with 23-amp current handling capability. The technical design of it ensures reliable power conversion for critical motor drive applications, maintaining stable operational characteristics across varying load conditions in industrial automation environments.

Manufactured under the Allen-Bradley brand with global certification compliance, the SINGLE PHASE PM3328B-6-1-3-E 80026-524-01 Allen Bradley1 features compact physical dimensions measuring 12.8×31.2×12.8 cm with a substantial weight of 4.46 kg, reflecting its robust construction and component density. The unit's electrical performance includes consistent 24V DC output with current delivery ranging from 8 to 12 amps, producing typical output power between 192-288 watts. These specifications make the Allen Bradley PM3328B-6-1-3-E 80026-524-01 particularly suitable for continuous operation in industrial settings where power stability directly impacts drive performance and system reliability.

The thermal management system integrated within the Allen Bradley PM3328B-6-1-3-E 80026-524-01 Power supply Module enables reliable operation across an extensive temperature spectrum from -25°C to +70°C, ensuring consistent performance in both climate-controlled and harsh industrial environments. This operational resilience is achieved through advanced cooling technologies and component selection that maintain optimal operating temperatures even under maximum load conditions. The design philosophy behind it prioritizes long-term reliability and minimal maintenance requirements, reducing total cost of ownership for industrial power infrastructure.

Within PowerFlex 7000 drive systems, the implementation of the Automation DCS power supply Allen Bradley PM3328B-6-1-3-E 80026-524-01 provides critical power conditioning and distribution functions that protect sensitive control electronics from power fluctuations and electrical noise. The unit's design incorporates multiple protection features including overcurrent protection, thermal shutdown, and voltage stabilization circuits that safeguard connected equipment against power anomalies. This comprehensive protection approach makes it an essential component for maintaining operational integrity in industrial automation systems where power quality directly influences production efficiency and equipment longevity.
