The 2711P-RN15S PanelView Plus ControlNet Communication Module is a ControlNet communication module designed for PanelView Plus and PanelView Plus CE HMI terminals. It supports both scheduled and unscheduled messaging for real-time industrial data exchange.

Application

Purpose & Device Compatibility: This module enables ControlNet communication for Allen-Bradley PanelView Plus and PanelView Plus CE HMI terminals (models 700-1500).

Messaging Support: It provides both scheduled and unscheduled messaging for flexible real-time industrial data exchange.

Software Integration: Requires RSView Studio (v3.20+) for development and RSView Machine Edition Runtime (v3.20.04.43+) to execute projects on the terminal.

Network Configuration: Setup and management of the module are performed using RSNetWorx for ControlNet (v5.11 or later).

Controller Interface: Works with ControlLogix PLCs programmed with RSLogix 5000 (v13.0 or later) over the ControlNet network.

Installation & Setup: A new module requires a communication configuration setup in the terminal's RSLinx Enterprise.

FAQ

Q1: What is the primary function of the Allen-Bradley 2711P-RN15S module?

A1: It is a ControlNet communication module designed to enable scheduled and unscheduled messaging for PanelView Plus and PanelView Plus CE HMI terminals.

Q2: Which PanelView terminals are compatible with the 2711P-RN15S module?

A2: It is compatible with PanelView Plus 700–1500 and PanelView Plus CE 700–1500 terminals.

Q3: What is required to configure this ControlNet communication module?

A3: You need to create a communication setup in RSLinx Enterprise and select the 2711P-RN15S ControlNet Scanner Card in the device selection window.

Q4: Does the 2711P-RN15S support firmware upgrades, and why is this important?

A4: Yes, it can be upgraded (e.g., from Rev. A to Rev. C) to enable scheduled messaging and improve compatibility, with firmware updates available from Rockwell Automation.

Q5: What software versions are required to use the 2711P-RN15S module?

A5: Required software includes RSView Studio v3.20+, RSView ME Runtime v3.20.04.43+, RSNetWorx for ControlNet v5.11+, and RSLogix 5000 v13.0+.
