1768-PA3 Product datasheet
|
Model number: |
1768-PA3 |
|
Module Type： |
CompactLogix Power Supplies |
|
Manufacture: |
Allen-Bradley |
|
Condition： |
Brand New |
|
Range of Product: |
Allen-Bradley |
|
Lead time： |
In Stock |
|
Weight: |
0.9kg |
|
HS CODE： |
8537101190 |
|
Dimension: |
3.5x13x14.5cm |
|
MOQ: |
1 |
|
Product Origin: |
USA |
|
System： |
PLC |
|
Discontinued on: |
Jane 30,2016 |
|
Communication Service: |
Ethernet router |
1768-PA3 Functional Description
The CompactLogix Power Supplies ROCKWELL 1768-PA3 is a dedicated power supply module for the 1768 CompactLogix system, delivering backplane power to connected controllers and modules. It accepts a wide input range of 85–265V AC or 108–132V DC. This Allen-Bradley 1768-PA3 unit must be installed in the same bank as the controller and is not compatible with 1769 power supplies.
Featuring an open-type enclosure, it supports both DIN rail and panel mounting. The module includes an LED status indicator for real-time operational monitoring. With a maximum input power of 120VA or 120W, the AB 1768-PA3 CompactLogix Power Supplies offers selectable inputs and typical efficiency of 75%.
This 1768-PA3 Power Supply ALLEN BRADLEY is designed to work specifically with 1768 controllers such as the L43, L43S, L45, and L45S. It can support up to eight 1769 I/O modules within the same bank. Proper power supply distance rating is essential to ensure stable backplane power distribution.
A green LED indicates normal operation, while no light may suggest a power issue or fault. A red LED signals invalid backplane power, a defective controller, or a faulty module. The CompactLogix power supply module Allen-Bradley 1768-PA3 includes built-in overcurrent protection with a non-replaceable fuse.
If you have other request contact our team to get customized service
Call +86 18159889985 to be connected with our Manager Stella
Email to sales6@apterpower.com get your best quotation
For the quick assistance message us on WhatsApp at +86 18159889985 now!
|
