ADLEE AS2-115 General-Purpose Inverter

ADLEE AS2-115 1.5 kW single-phase input motor drive

Inquiry now

ADLEE AS2-115 General-Purpose Inverter

Single-phase 200-240 VAC input drive for controlled operation of 1.5 kW three-phase motors.

Product Overview

The ADLEE AS2-115 is an AS Series general-purpose inverter designed to convert a single-phase 200-240 VAC supply into a controlled three-phase 220 VAC motor output. The official ADLEE manual identifies this model for a maximum 1.5 kW four-pole motor, with an 8 A rated output, 2.7 kVA capacity and a standard 0.5-400 Hz frequency range. Sine-wave PWM control, regenerative discharge braking and adjustable acceleration and deceleration support practical industrial speed-control duties.

Commercial Status

Item	Verified Information
Manufacturer	ADLEE POWERTRONIC CO., LTD.
Complete Part Number	AS2-115
Product Type	General-Purpose Inverter / Variable Frequency Drive
Series	ADLEE AS Series
Lifecycle Status	Not stated in the accessible official manufacturer documentation
Technical Basis	ADLEE AS Series official instruction manual

Verified Technical Data

Parameter	AS2-115 Specification
Input supply	Single-phase 200-240 VAC ±10%
Input frequency	50-60 Hz ±10%
Output voltage	Three-phase 220 VAC
Output frequency	0.5-400 Hz
Rated output current	8 A
Capacity	2.7 kVA
Maximum applicable motor	1.5 kW, four-pole motor
Control method	Sine-wave pulse-width modulation
Braking	Regenerative discharge braking
Overcurrent capacity	150% of rated current for 1 minute
Acceleration / deceleration	0.1-6000 seconds
Enclosure / protection	IP20, Protective Class I
Cooling method	Air-cooled
Net weight	Approximately 1.3 kg

System Fit and Applications

AS2-115 is suited to equipment that has a suitable single-phase 200-240 VAC source and a three-phase 220 VAC motor within the verified current and power limits. Typical uses may include speed control for pumps, fans, conveyors and compact machinery after the motor load profile has been checked.

Engineering note: Motor voltage, full-load current, acceleration torque, braking duty, enclosure conditions and control-terminal requirements must be reviewed for the actual machine.

Compatibility and Procurement Checks

Confirm the exact nameplate model is AS2-115 without an additional R, H, N or other suffix.
Verify a single-phase 200-240 VAC input and a three-phase 220 VAC motor are required.
Confirm the motor is no larger than 1.5 kW and its rated current is compatible with the 8 A output.
Review wiring, grounding, external braking-resistor needs and control-terminal logic against the machine drawings.
Check installation ventilation, IP20 enclosure suitability and ambient conditions before retrofit work.
Request current availability, condition, included accessories and warranty scope before ordering.

Lifecycle Note

The accessible ADLEE official documentation confirms the AS2-115 model and its technical ratings but does not state a current lifecycle classification. No Active, Legacy, Discontinued or other lifecycle label is assigned on this page without manufacturer wording. Procurement teams should request present support and availability confirmation.

Frequently Asked Questions

What is the ADLEE AS2-115?

It is an AS Series general-purpose inverter for operating a compatible three-phase motor from a single-phase 200-240 VAC supply.

What motor rating does AS2-115 support?

The official manual specifies a maximum 1.5 kW four-pole motor, subject to motor current, torque and duty verification.

What are the input and output ratings?

The verified input is single-phase 200-240 VAC ±10%, while the motor output is three-phase 220 VAC with an 8 A rating.

What frequency range is available?

The standard AS2-115 specification provides a 0.5-400 Hz output frequency range.

Can AS2-115 replace another AS Series drive automatically?

No. Confirm the complete suffix, input class, motor current, terminal functions, parameter set, dimensions and braking arrangement before replacement.

What should be checked before procurement?

Verify the AS2-115 nameplate, motor data, supply voltage, installation environment, required accessories, condition, availability and warranty terms.

Verify AS2-115 Before Procurement

Contact Stockoems for availability verification, compatibility review, warranty terms and worldwide delivery coordination.

sales6@apterpower.com|WhatsApp: +86 181 5988 9985

Request Product Support Email Sales WhatsApp

Stockoems Service for AS2-115

Procurement support, condition review and international delivery coordination for industrial replacement requirements.

Procurement Support

For AS2-115 enquiries, our team checks the complete model reference, available unit condition, visible nameplate data and supplied accessories before commercial confirmation. Compatibility remains dependent on the buyer's motor, supply, wiring and machine requirements.

Office Coordination

Documentation, quotation preparation and order coordination handled by the Stockoems team.

Industrial spare parts visual inspection

Visible Condition Review

Available units can be reviewed for model identity, exterior condition and package completeness.

Packing and Dispatch

Order handling supports protective packing and worldwide delivery coordination.

Information to Provide

Clear photo of the existing nameplate showing AS2-115 and any suffix.
System, load or application data relevant to the installed equipment.
Machine wiring, terminal or accessory requirements.
Requested condition, quantity, destination country and required delivery date.

Discuss Your AS2-115 Requirement

Send the complete model and application details for availability and compatibility review.
