ABB PFSK142 3BSE006505R1 Control Board

Inquiry now

PFSK142 3BSE006505R1 Product datasheet

Model number:	PFSK142 3BSE006505R1	Module Type：	Control Board
Manufacture:	ABB	Condition：	Brand New
Range of Product:	Advant OCS/800xA	Lead time：	In Stock
Weight:	0.4 kg	HS CODE：	8537101190
Dimension:	6x25.8x24.3cm	MOQ:	1
Product Origin:	SWEDEN	System：	DCS
Discontinued on:	Active	Communication Service:	Ethernet router

PFSK142 3BSE006505R1 Functional Description

The ABB PFSK142 3BSE006505R1 Control Board is an advanced 32-channel control board featuring precision signal conversion capabilities. At its core are two high-resolution converters - an 16-bit DAC80508 and 14-bit DAC70508 digital-to-analog converter, complemented by dual 24-bit ADS122C04/U04 analog-to-digital converters with I²C/UART interfaces. This sophisticated architecture ensures exceptional measurement accuracy for industrial automation systems.

Powered by a 32-bit ARM Cortex-R5F processor running at 500 MHz, the DCS Module Controller PFSK142 3BSE006505R1 ABB delivers real-time processing performance while operating at 24V DC (±10%) with ≤10W power consumption. The board's robust design includes 1500V AC reinforced isolation (field-to-system) and 250V AC channel-to-channel isolation, making it suitable for demanding industrial environments.

The ABB PFSK142 Distributed Control Card maintains reliable operation across an extended -25°C to +70°C temperature range, with storage tolerance from -40°C to +85°C. Its vibration-resistant construction (5-100Hz) and humidity resilience (5-95% non-condensing) ensure continuous performance in challenging conditions typical of manufacturing and process industries.

As part of ABB's industrial control solutions, the 3BSE006505R1 Processor Motherboard PFSK142 ABB combines high-density I/O processing with industrial-grade durability. The board's precision converters and powerful processing capabilities make it ideal for critical applications requiring accurate analog signal acquisition and generation in automation systems..
