ABB IMDSM05 is a Harmony Rack Series digital input/output module for 24 VDC discrete field signals. It provides 16 channels that can be selected as inputs or outputs in groups of eight, allowing one rack module to support a defined two-bank I/O arrangement. The module communicates through the Harmony rack I/O expander bus and works with the appropriate termination and field wiring configuration. It is relevant to maintenance replacement, validated system extension and migration assessment. Before ordering, confirm each eight-channel group assignment, termination hardware, dipshunt, wiring polarity, DLS use and controller database.
| Manufacturer | ABB |
|---|---|
| Complete Part Number | IMDSM05 |
| Product Type | 16-channel digital input/output module |
| Series | Harmony Rack Series |
| Channel Configuration | 16 channels; selectable as inputs or outputs in groups of eight |
| Signal Range | 24 VDC |
| Product Condition | NEW |
| Country of Origin | SWEDEN |
| Compatibility | Harmony rack I/O installation subject to termination, wiring and configuration review |
| Warranty | With 1 year warranty |
| Shipping | Worldwide shipping options are reviewed during quotation. |
ABB migration material identifies separate input and output paths, but it does not present a direct replacement when IMDSM05 is used for both duties or with a Digital Logic Station.
For output migration, review SPDSO14 and wiring polarity requirements. For input migration, review SPDSI22 and the required dipshunt arrangement. Engineering confirmation is essential.
Confirm the complete IMDSM05 part number, both eight-channel group assignments, 24 VDC signal duty, termination unit, dipshunt, field-wire polarity, hardware revision, controller configuration, rack position, mounting arrangement and any Digital Logic Station use. Compare original equipment label photos before ordering.
Availability is checked against the required quantity, condition, destination and exact label details during quotation.
ABB documentation states that inputs or outputs are selected in groups of eight, so confirm both bank assignments.
Do not assume a direct replacement. The correct path depends on input/output duty, dipshunt, wiring polarity and Digital Logic Station use.
Send the module label, termination details, both bank assignments, field wiring photos, rack position and controller configuration information.
Worldwide shipping options, protective packaging and customs documentation are reviewed after destination and quantity are confirmed.
