ABB 086444-001 MPRC 086444-001 Scanning Board

Inquiry now

086444-001 MPRC 086444-001 Product datasheet

Model number:	086444-001 MPRC 086444-001	Module Type：	Scanning Board
Manufacture:	ABB	Condition：	Brand New
Range of Product:	ABB	Lead time：	In Stock
Weight:	1.22 kg	HS CODE：	8537101190
Dimension:	24x19x5.3cm	MOQ:	1
Product Origin:	SWEDEN	System：	DCS
Discontinued on:	Active	Communication Service:	Ethernet router

086444-001 MPRC 086444-001 Functional Description

The ABB 086444-001 MPRC 086444-001 SCANNING BOARD represents an advanced Ethernet-enabled MPRC board specifically engineered for industrial automation environments. This sophisticated controller features comprehensive diagnostic LEDs including ERROR and RUN indicators that provide real-time status monitoring of board operations and processor activity. The dual Ethernet ports on 086444-001 MPRC 086444-001 ABB BOARD support simultaneous data transmission through both J2 connector and ASPC host interface, ensuring redundant communication capabilities.

Network connectivity forms the core advantage of SCANNING BOARD 086444-001 ABB, with dedicated TX indicators displaying active data transmission through both Ethernet channels. The board additionally incorporates multiple HDLC ports for sensor communication, though ports 2 and 3 remain unused in standard Smart Platform configurations. These communication features make ABB 086444-001 particularly suitable for complex automation systems requiring robust data exchange.

Installation of the 086444-001 MPRC board ABB requires specific fiberoptic components to meet European CE Mark standards, including the recommended the cable with ST connectors. The Ethernet connection utilizes a specialized Y-cable that interfaces with the J6 host connector on the ASPC backplane, while the redundant port typically routes through a shielded grounding block on the enclosure door. This careful design ensures electromagnetic compatibility in industrial settings.

Through its integrated diagnostic system and dual-network capability, the ABB DRIVES 086444-001 MPRC 086444-001 delivers reliable performance in demanding control applications. The board's sophisticated LED indicators enable quick troubleshooting while maintaining continuous operation, making it an essential component in modern industrial automation infrastructure where network reliability and diagnostic visibility are paramount for system uptime.
