External operating panel for remote control of a compatible SINAMICS V20 converter.
The Siemens 6SL3255-0VA00-4BA1 is an external SINAMICS V20 Basic Operator Panel designed for remote operation of a compatible converter. It provides a cabinet-door operating interface so users can access drive controls and parameters away from the converter body. Siemens specifies 76 × 85 × 30 mm dimensions, an operating range of −10 °C to 50 °C, and IP54 or UL Type 1 enclosure capability when correctly mounted. Connection requires the appropriate SINAMICS V20 BOP Interface and a directly connected shielded Ethernet cable. Before ordering, verify the complete suffix, interface module, cable length, cabinet cutout and target converter configuration.
| Item | Stockoems Commercial Information |
|---|---|
| Product Condition | Original new |
| Availability | In stock |
| Warranty | With 1 year warranty |
| Shipping | Worldwide shipping options available |
Condition, availability and warranty are Stockoems commercial terms and are not manufacturer commitments.
| Parameter | Verified Value |
|---|---|
| Manufacturer | Siemens |
| Complete Part Number | 6SL3255-0VA00-4BA1 |
| Product Type | SINAMICS V20 External Basic Operator Panel |
| Function | Remote converter operation |
| Dimensions (W × H × D) | 76 × 85 × 30 mm |
| Permissible Operating Temperature | −10 °C to 50 °C |
| Enclosure Capability | IP54 / UL Type 1 when correctly mounted |
| Required Connection Component | SINAMICS V20 BOP Interface, article 6SL3255-0VA00-2AA1 |
| Connection Cable | Directly connected shielded Ethernet cable, maximum 3 m for EMC compliance |
| Package Contents | External BOP and four M3 screws |
The external BOP provides the remote human-machine operating point.
The separately ordered interface connects the panel to the converter.
A shielded Ethernet cable links the interface to the SINAMICS V20.
| Check Point | Required Verification |
|---|---|
| Complete suffix | Match 6SL3255-0VA00-4BA1 character for character. |
| Drive family | Confirm the target converter is a compatible SINAMICS V20 configuration. |
| Interface | Plan for the separate BOP Interface 6SL3255-0VA00-2AA1. |
| Cable and EMC | Use a directly connected shielded Ethernet cable no longer than 3 m. |
| Panel mounting | Confirm the cabinet cutout, fastening points and enclosure requirement. |
It is an external SINAMICS V20 Basic Operator Panel for remote converter operation.
No. Siemens lists the BOP Interface as a separate component; the specified interface article is 6SL3255-0VA00-2AA1.
Use a directly connected shielded Ethernet cable. Siemens specifies a maximum length of 3 m for EMC compliance.
When correctly mounted, the panel is designed for IP54 and UL Type 1 enclosure capability.
Verify the complete suffix, target V20 converter, BOP Interface, cable, cabinet cutout and product label photos.
