Sixteen-channel basic voltage acquisition for SIMATIC S7-1500 automation systems.
Siemens identifies 6ES7531-7LH00-0AB0 as the SIMATIC S7-1500 AI 16xU BA analog input module. It provides sixteen voltage input channels in one group, 16-bit resolution, diagnostics and hardware interrupts.
The module is designed for basic voltage measurement in an S7-1500 station. Its front connector must be ordered separately, and engineering compatibility must be checked against the CPU, TIA Portal or STEP 7 environment, configured input range and field wiring.
| Complete Siemens order number | 6ES7531-7LH00-0AB0 |
| Official device designation | S7-1500 AI 16xU BA analog input module |
| Official exact-model evidence | Siemens official technical data sheet and Industry Mall |
| Lifecycle statement | PM300: Active Product |
| Manufacturer | Siemens |
| Product family | SIMATIC S7-1500 |
| Product type designation | AI 16xU BA |
| Analog inputs | 16 voltage channels; one group of 16 |
| Resolution | 16 bit |
| Accuracy | 0.5% |
| Supported input range | 1 to 5 V |
| Common-mode voltage | 4 V DC |
| Power loss | 0.75 W |
| Net weight | 0.367 kg |
Place three current photographs below to verify the complete order number, connection area and physical condition.
 |
 |
 |
| Application | Engineering Relevance |
|---|---|
| Centralized voltage acquisition | Collects sixteen compatible voltage signals in one S7-1500 module. |
| Process and machine monitoring | Feeds documented analog measurements to control, alarming and trending functions. |
| Cabinet modernization | Adds dense basic analog input capacity within a validated S7-1500 configuration. |
| Maintenance replacement | Supports exact-model replacement when range, connector, firmware and project settings match. |
Siemens lists 6ES7531-7LH00-0AB0 as PM300: Active Product. Keep this exact order number in procurement records because other SM 531 analog input variants have different channel types and configurations.
It is the S7-1500 AI 16xU BA sixteen-channel voltage analog input module.
Siemens specifies sixteen voltage inputs in one group of sixteen.
The official data sheet specifies 16-bit resolution.
No. Siemens states that the front connector must be ordered separately.
The data sheet lists TIA Portal V16 with HSP 312 or V17, and STEP 7 V5.5 SP3.
Provide the exact model, quantity, voltage ranges, destination and photos of the module label and connector area.
Send the exact part number, quantity, destination and required condition for availability, compatibility and warranty review.
A structured review of signal type, module identity, engineering fit, condition evidence and protected delivery.
