6ES7334-0CE01-0AA0 Overview

The Siemens ANALOG INPUT/OUTPUT SM 334 6ES7334-0CE01-0AA0 is an analog I/O module for S7-300 PLCs, featuring four 8-bit inputs and two 8-bit outputs, supporting 0-10V/0-20mA signals with a non-isolated backplane connection.

Features and benefits

Compact Design: Small dimensions for space-saving integration within S7-300 systems.

Flexible I/O: Provides four analog inputs and two analog outputs for versatile signal processing.

Dual Signal Support: Handles both 0-10V and 0-20mA input/output signals via hardware wiring.

Power Efficiency: Low power consumption and dissipation enhance system energy performance.

Easy Configuration: Non-parameterizable design simplifies setup through physical wiring.

Stable Operation: Designed for operation with 24VDC power, ensuring compatibility and reliability.

FAQ

Q1: What is the main function of the Siemens 6ES7334-0CE01-0AA0 module?

A1: It is an analog I/O module for the S7-300 PLC series, providing four inputs and two outputs for voltage or current signals.

Q2: What analog signals does this module support?

A2: It supports both voltage (0-10V) and current (0-20mA) signals for both its inputs and outputs.

Q3: Is this a parameterizable module?

A3: No, it is not parameterizable. The measurement and output types are configured directly through the hardware wiring.

Q4: What are the electrical isolation characteristics of this module?

A4: It is isolated from the load voltage but is non-isolated against the backplane bus. There is also no isolation between its own channels.

Q5: What is the power requirement for this module?

A5: It operates on a 24VDC rated load voltage and draws a maximum of 110 mA (no load) from the power supply.
