Optical PROFINET communication interface for distributed ET 200iSP station integration.
Siemens 6ES7152-1BA00-0AB0 is the SIMATIC ET 200iSP IM 152-1PN interface module for connecting a distributed I/O station to PROFINET IO. Official Siemens technical data identifies a two-port optical LC interface with an integrated switch, multimode fiber support and transmission rates up to 100 Mbit/s. The documented multimode cable distance is up to 3,000 m for 50/125 µm and 62.5/125 µm fiber. Installation and replacement work should verify the ET 200iSP station design, power-supply arrangement, approved optical components, rail mounting, PROFINET name and addressing, engineering software versions, redundancy design and hazardous-area documentation.
IM 152-1PN for ET 200iSP
Siemens documentation confirms the complete order number and its optical PROFINET interface function.
| Product Condition | Original new |
| Availability | In stock |
| Warranty | With 1 year warranty |
| Shipping | Worldwide shipping options available |
Condition, availability and warranty are Stockoems commercial information, not manufacturer commitments.
| Manufacturer | Siemens |
| Complete Part Number | 6ES7152-1BA00-0AB0 |
| Product Family | SIMATIC ET 200iSP |
| Product Type | IM 152-1PN interface module |
| Bus System | PROFINET IO |
| Transmission Rate | Up to 100 Mbit/s |
| Interface Design | Optical multimode fiber |
| Optical Connector | LC |
| Number of Ports | 2 |
| Integrated Switch | Yes |
| Multimode Fiber Distance | Up to 3,000 m |
| Supported Fiber Sizes | 50/125 µm and 62.5/125 µm |
| Rated Supply | 11.5 V DC supply; 3.55 V bus |
| Maximum Input Current | 150 mA from load voltage |
| Typical Power Loss | 1.6 W |
| Mounting | Front mounting with rail; rail mounting |
| Country of Origin | Germany |
| Application Area | How the Product Is Used |
| ET 200iSP PROFINET connection | Connects a compatible distributed I/O station to an optical PROFINET network. |
| Hazardous-area system design | Requires the specified station enclosure, approved optical components and project documentation for the installation. |
| Long-distance optical networking | Supports multimode fiber links after fiber type, connector, topology and attenuation are verified. |
| Installed-base replacement | Supports maintenance after station configuration, module version, addressing and engineering software are checked. |
It identifies the Siemens SIMATIC ET 200iSP IM 152-1PN interface module for PROFINET IO.
Siemens documents two optical LC ports, an integrated switch and transmission rates up to 100 Mbit/s.
The official technical data lists 50/125 µm and 62.5/125 µm multimode fiber with cable lengths up to 3,000 m.
No. Verify the station design, optical components, power arrangement, PROFINET configuration, software version and any redundancy architecture.
No official lifecycle wording was verified in the reviewed Siemens technical references, so no lifecycle conclusion is stated.
Request readable order-code, approval-label, optical-interface, housing, terminal and packaging photos before shipment.
Send us the complete part number, required quantity, destination country and product label photos. Our team will check availability, condition, compatibility requirements and shipping options.
A documented procurement workflow for Siemens 6ES7152-1BA00-0AB0 and replacement planning.
The complete model, suffix, markings and visible condition are checked against the inquiry.
The review covers ET 200iSP station, optical LC ports, fiber type, power arrangement, PROFINET settings and engineering versions.
Product protection, shipment documents and tracking are coordinated before dispatch.
| Control Point | What We Review |
| Identity | Brand, complete model, suffix, readable label and approval markings |
| Technical context | ET 200iSP station, optical LC ports, fiber type, power arrangement, PROFINET settings and engineering versions |
| Visual inspection | housing, LEDs, optical ports, rail interface, label, terminals and visible condition |
| Packaging | optical-port protection, antistatic handling, cushioning and outer-carton support |
| Logistics | Destination, carrier option, tracking and customs paperwork |
| After-sales | Written warranty, order record, inspection evidence and return authorization route |
Check whether the supplier records the complete part number, provides readable product and label photos, states condition and warranty terms in writing and avoids unsupported compatibility claims.
Request the commercial offer, complete model, condition statement, inspection photos, packaging plan, shipping method, warranty terms and return authorization procedure.
Review ET 200iSP station, optical LC ports, fiber type, power arrangement, PROFINET settings and engineering versions.
Risk signals include incomplete suffixes, hidden labels, unsupported compatibility claims, vague warranty wording and promises of unverified stock quantities or delivery dates.
Yes. Available photos can cover the complete unit, readable label, key interfaces, packaging and visible accessories.
Send us the complete part number, required quantity, destination country and product label photos. Our team will check availability, condition, compatibility requirements and shipping options.
