Siemens 6AG1214-2BD23-2XB0 SIPLUS S7-200 CPU 224XP

Siemens 6AG1214-2BD23-2XB0 Extended-Temperature AC/DC/Relay Compact CPU

Inquiry now

SIPLUS S7-200 · COMPACT CONTROL

6AG1214-2BD23-2XB0

Extended-temperature CPU 224XP with integrated digital and analog I/O

Controller profile

CPU 224XP

14 DI · 10 relay DO · 2 AI · 1 AO

Product Overview

The Siemens 6AG1214-2BD23-2XB0 is a SIPLUS S7-200 CPU 224XP for demanding environmental conditions. Siemens documentation identifies it as an AC/DC/Relay compact CPU based on the standard article 6ES7214-2BD23-0XB0.

The controller combines onboard digital and analog I/O, two RS-485 communication ports, integrated real-time clock functions and support for up to seven expansion modules. Project and environmental compatibility must be checked for the installed S7-200 system.

Procurement Snapshot

Family: SIPLUS S7-200

CPU: CPU 224XP

Variant: AC/DC/Relay

Temperature: −25 to +70 °C

Commercial Status

Lifecycle	Not stated in the accessible Siemens documentation for this exact article
Official article note	SIPLUS CPU 224XP based on 6ES7214-2BD23-0XB0
Successor	No article-specific successor confirmed
Supply approach	Verify exact article, CPU revision, program backup and installed expansion

Verified Technical Data

Parameter	Official specification	Procurement significance
Product type	SIPLUS S7-200 CPU 224XP	Match the extended-temperature SIPLUS article.
Power/output variant	AC/DC/Relay	Confirm supply and relay-load requirements.
Digital I/O	14 digital inputs and 10 relay outputs	Check the onboard wiring allocation.
Analog I/O	2 analog inputs and 1 analog output	Verify signal range and scaling.
Program memory	12,288 bytes with run edit; 16,384 bytes without run edit	Confirm project size and operating mode.
Data memory	10,240 bytes	Check program data requirements.
Expansion capacity	Up to 7 expansion modules	Validate total I/O configuration.
Communication	2 RS-485 ports	Confirm network mode, addresses and cabling.
Environmental range	−25 to +70 °C	Use the SIPLUS environmental rating in cabinet review.
Dimensions	140 × 80 × 62 mm	Check rail and cabinet space.

System Fit and Applications

Compact machine control

Run mixed digital and analog logic in legacy S7-200 installations.

Harsh-environment cabinets

Use SIPLUS environmental capability where the complete installation supports it.

Installed-base replacement

Replace a CPU 224XP only with validated program, memory and expansion compatibility.

Compatibility and Procurement Checks

1. Article identity

Confirm the complete 6AG1214-2BD23-2XB0 number and hardware revision.

2. Program recovery

Secure project files, passwords, memory cartridge data and parameter records.

3. I/O and network

Verify AC supply, relay loads, analog signals, RS-485 cabling and expansion modules.

4. Supply scope

Confirm CPU condition, accessories, warranty, quantity and destination.

Lifecycle Note

Accessible Siemens documentation confirms the exact SIPLUS article and its CPU 224XP basis, but does not state a current lifecycle code for 6AG1214-2BD23-2XB0. No Active, phase-out, cancellation or discontinued label has been inferred.

Frequently Asked Questions

What is the Siemens 6AG1214-2BD23-2XB0?

It is a SIPLUS S7-200 CPU 224XP AC/DC/Relay compact controller for extended-temperature operation.

Which standard CPU is it based on?

Siemens documentation identifies the basis as 6ES7214-2BD23-0XB0.

What onboard I/O is provided?

The CPU 224XP configuration has 14 digital inputs, 10 relay outputs, 2 analog inputs and 1 analog output.

How many expansion modules are supported?

Official S7-200 system data specifies up to seven expansion modules for CPU 224XP.

Is a current lifecycle status confirmed?

No. The accessible official documentation confirms the article but does not provide a current exact lifecycle code, so none is inferred.
