ProSoft MVI69-MCM Modbus Master/Slave Communication Module

Inquiry now

MVI69-MCM Product datasheet

Model number:	MVI69-MCM	Module Type：	Modbus Master/Slave Communication Module
Manufacture:	Prosoft	Condition：	Brand New
Range of Product:	ControlLogix	Lead time：	In Stock
Weight:	0.14 kg	HS CODE：	8537101190
Dimension:	3.8x8.6x13cm	MOQ:	1
Product Origin:	USA	System：	PLC
Discontinued on:	Active	Communication Service:	Ethernet router

MVI69-MCM Functional Description

The ProSoft MVI69-MCM Modbus Master/Slave Communication Module module requires installation in a Rockwell Automation CompactLogix or MicroLogix chassis with 800mA available power, ensuring reliable operation as a Modbus communication gateway. This versatile module occupies a single slot while providing dual serial ports for connecting to Modbus RTU/ASCII networks, making the Interface Module ProSoft MVI69-MCM ideal for industrial automation upgrades.

To program the ProSoft PLC Modules MVI69-MCM, users need RSLogix 5000 (CompactLogix) or RSLogix 500 (MicroLogix) software alongside RSLinx for communication. The module's 32KB user memory stores configuration data and mapping tables, while supporting baud rates up to 115.2kbps for flexible network integration.

A Pentium III 733MHz (or better) processor with 256MB RAM is recommended for configuring the ProSoft Modbus Master/Slave Network Interface ModuleMVI69-MCM, though it can operate with minimum specs of Pentium II 450MHz/128MB RAM. The development PC requires 100MB disk space and runs on legacy Windows systems (XP/2000/Server 2003), ensuring compatibility with existing industrial IT infrastructure.

The MVI69-MCM ProSoft PDF setup utilizes a CD-ROM drive and terminal emulator (like HyperTerminal) for firmware updates via Ymodem protocol. Its 1756 backplane compatibility and modest power requirements make this Modbus solution particularly valuable for retrofitting older control systems with modern communication capabilities.

If you have other request contact our team to get customized service

One Year Warranty

We offer a one-year warranty for any quality issues with our products. If you encounter any defects or malfunctions during this period, please contact us for prompt resolution. Our warranty covers repairs or replacements, ensuring your satisfaction and peace of mind.
Shipping & Delivery

We have 10 years experience with leading logistics companies like FedEx, DHL, and SF, ensuring efficient and reliable shipping solutions. Our extensive experience in working with these carriers allows us to offer fast, secure delivery services, tailored to meet the diverse needs of our customers.
Payment Method

We accept a variety of payment methods, including T/T Bank Transfer, Alipay, and more, providing flexible options to suit our customers' preferences. This ensures a convenient and secure transaction process for all orders.

How Can I Get Your Support?

Call +86 18159889985 to be connected with our Manager Stella

Email to sales6@apterpower.com get your best quotation

For the quick assistance message us on WhatsApp at +86 18159889985 now!

You can also reach me via Skype: live:ariatang111 or WeChat: zxd18159889985!

Prosoft	MVI69-PDPMV1	Prosoft	MVI71-AFC	Prosoft	MVI56-HART
Prosoft	PS69-DPM	Prosoft	MVI71-ADM	Prosoft	MVI56-GSC
Prosoft	PLX32-EIP-PND	Prosoft	MVI69-MNETC	Prosoft	MVI56-GEC
Prosoft	PLX31-MBTCP-MBS	Prosoft	MVI69L-MBTCP	Prosoft	MVI56E-MNETXT
Prosoft	PLX31-EIP-PND	Prosoft	MVI69L-MBS	Prosoft	MVI56E-MNETR
Prosoft	PLX31-EIP-MBS	Prosoft	MVI69-DFNT	Prosoft	MVI56E-MNETCR
Prosoft	PC56-2K-IDE	Prosoft	MVI69-ADMNET	Prosoft	MVI56E-MNET
Prosoft	MVI94-MCM	Prosoft	MVI69-ADM	Prosoft	MVI56E-MCMXT
Prosoft	MVI94-ADM	Prosoft	MVI56-PDPMV1	Prosoft	MVI56E-MCMR
Prosoft	MVI71-MNET	Prosoft	MVI56-MDA4	Prosoft	MVI56E-MCM

MVI69-MCM CompactLogix or MicroLogix Platform User Manual Modbus Communication Module

The MVI69-MCM module requires the following minimum hardware and software components:

Rockwell Automation CompactLogix or MicroLogix processor, with compatible power supply and one free slot in the rack, for the MVI69-MCM module. The module requires 800 mA of available power.

Rockwell Automation RSLogix 5000 (CompactLogix) or RSLogix 500 (MicroLogix) programming software

Rockwell Automation RSLinx communication software

Pentium® II 450 MHz minimum. Pentium III 733 MHz (or better) recommended

Supported operating systems:

o Microsoft Windows XP Professional with Service Pack 1 or 2

o Microsoft Windows 2000 Professional with Service Pack 1, 2, or 3

o Microsoft Windows Server 2003

128 Mbytes of RAM minimum, 256 Mbytes of RAM recommended

100 Mbytes of free hard disk space (or more based on application requirements)

256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color 1024 × 768 recommended)

CD-ROM drive

HyperTerminal or other terminal emulator program capable of file transfers using Ymodem protocol.
