EDS-208A Overview

The Unmanaged Switches EDS-208A Moxa are rugged 8-port industrial Ethernet switches with dual redundant power inputs, designed to operate reliably in harsh environments from -40 to 75°C. They support a wide range of industrial and hazardous location certifications for maritime, rail, and mobile applications.

Features and benefits

Network Interface: Provides both 10/100BaseT(X) RJ45 and 100BaseFX fiber ports for flexible connectivity.

Power Design: Supports dual 12/24/48 VDC redundant power inputs, ensuring continuous operation.

Robust Housing: IP30-rated aluminum enclosure protects against physical and environmental damage.

Harsh Environment Suitability: Certified for hazardous areas, transportation, and maritime applications.

Wide Temperature Range: Operates reliably from -40°C to 75°C, ideal for extreme industrial conditions.

Industrial Standards: Fully complies with FCC, UL, CE, and other key industry certifications.

FAQ

Q1: What is the primary function of the Moxa EDS-208A?

A1: It is an 8-port industrial Ethernet switch designed to provide reliable network connectivity in harsh environments.

Q2: What are the power input options for the EDS-208A?

A2: It supports dual redundant power inputs with a wide range of 12/24/48 VDC (9.6 to 60 VDC) for flexible and resilient power supply.

Q3: In what kind of environments can the EDS-208A operate?

A3: It is designed for harsh industrial settings, including hazardous locations (Class I Div. 2, ATEX Zone 2), maritime, railway, and mobile applications.

Q4: What temperature range can the EDS-208A withstand?

A4: It is available with a standard range of -10°C to 60°C or a wide range of -40°C to 75°C for extreme temperature conditions.

Q5: Does the EDS-208A support fiber optic connections?

A5: Yes, it offers 100BaseFX ports with SC or ST connectors for both multi-mode and single-mode fiber connections.
