T9481 Overview

The Analogue Output Module T9481 ICS Triplex  is a precision analog output module delivering isolated voltage or current signals with 14-bit resolution and ±0.1% accuracy for reliable industrial control.

Environment and Certification

Operating Temperature: Functions reliably from 0°C to +60°C.

Storage Temperature: Withstands storage from –40°C to +85°C.

Humidity Tolerance: Operates in 5 – 95% relative humidity (non-condensing).

Electrical Isolation: Features 1500 V dc isolation for safety.

Product Compliance: Certified for use in the AADvance 9000 series safety systems.

Manufacturing Standards: Produced under ICS Triplex's industrial quality and reliability standards.

FAQ

Q1:What core type and channel configuration does the ICS Triplex T9481 have?

A1:It is an isolated 3/8 channel analogue output module.

Q2:What power supply and power consumption does the T9481 module feature?A2 It uses 24 V dc power and has a module consumption of 3.3 W.

Q3: What output voltage and current ranges does the T9481 support?A3 It supports voltage ranges of ±10 V and 0–10 V, and a current range of 0–20 mA.

Q4: What are the key performance specs for T9481’s resolution and accuracy?

A4: It has 14-bit resolution and ±0.1% of full scale accuracy at 25 °C.

Q5 :What is the isolation rating and operating temperature range of the T9481?

A5: It has a 1500 V dc isolation rating and an operating temperature range of 0 – +60 °C.
