General Electric IS220PSFDH1A Power Supply

Inquiry now

IS220PSFDH1A Product datasheet

Model number:	IS220PSFDH1A	Module Type：	Power Supply
Manufacture:	GE	Condition：	Brand New
Range of Product:	EX2100	Lead time：	In Stock
Weight:	0.38 kg	HS CODE：	8537101190
Dimension:	12.8x8.2x6cm	MOQ:	1
Product Origin:	USA	System：	DCS
Discontinued on:	Active	Communication Service:	Ethernet router

IS220PSFDH1A Functional Description

The Flame Detector Power Supply GE IS220PSFDH1A is a critical component of the Mark VI turbine control system, designed to provide reliable power for flame detection in gas turbine operations. This robust power supply delivers 335V DC output (with 5% tolerance) capable of supporting up to eight flame detectors through its unique triple modular redundant (TMR) diode-ORed configuration, ensuring continuous operation even if two power supplies fail. The General electric IS220PSFDH1A Power Supply features a wide operating range of -30°C to 65°C with convection cooling and provides 1700V DC isolation for enhanced safety.

Key technical specifications include 28V DC input (26.6-29.4V range), 7mA current limit, and soft-start capability (550mA inrush current limit). The unit incorporates three diagnostic LEDs, over-voltage protection, and filtered input to minimize electromagnetic interference. The IS220PSFDH1A Phoenix Controls General Electric conformal PCB coating enhances durability while maintaining its functional A-rated revision status, representing a performance-focused upgrade within GE's Speedtronic control technology lineage.

Installation involves mounting above the TRPG terminal board with proper chassis grounding (FE). Electrical connections require: 1) 335V DC output to TRPG's J3/J4/J5 via 2x2 connector P2, and 2) 28V DC input through 1x3 connector P1 which features built-in soft-start functionality. The IS220PSFDH1A Power Supply 335 VDC compact design eliminates need for cooling fans while maintaining reliable operation.

As part of the advanced Mark VI series, the Power Supply 335 VDC GE IS220PSFDH1A represents significant improvements over previous Mark V systems, extending application capabilities to include wind turbine controls while maintaining GE's patented Speedtronic technology. Its robust design and fail-safe features make it essential for critical turbine protection systems in power generation applications.
