IS210TREAH1A Overview

The General Electric Conformal Coated Printed Circuit Board IS210TREAH1A is a temperature input module from the Mark VIe industrial turbine control system. It is designed to reliably acquire and process temperature signals, featuring robust electrical isolation and high measurement accuracy for critical power generation applications.

Technical Data Summary

• Product Series & Type: IS210 series, Temperature Input module ("TREA" function code), conformal coated PCB for environmental protection.

• System Platform: Designed for the Mark VIe gas/steam turbine control system, signified by the "H1" grouping in the part number.

• Hardware Revision: Features a single functional revision, indicated by the final "A" revision grade.

• Key Hardware: Populated with multiple integrated circuits and components, consistent with a signal conditioning I/O module.

• Primary Function: Dedicated to acquiring and processing temperature signals (e.g., from RTDs or thermocouples) for turbine control and monitoring.

FAQ

Q1: What is the primary function of the IS210TREAH1A module?

A: It is a temperature input module designed to acquire and process signals from temperature sensors (such as RTDs or thermocouples) in General Electric's Mark VIe turbine control systems.

Q2: What does the "TREA" in the part number indicate?

A: The "TREA" is a functional acronym specific to GE Mark VIe system I/O modules, indicating its dedicated role in temperature signal acquisition and conditioning.

Q3: Is the IS210TREAH1A module environmentally protected?

A: Yes. As part of the IS210 series, it features a conformal coating on its printed circuit board to protect against dust, moisture, and corrosive contaminants in industrial environments.

Q4: What does the revision code "A" at the end of the part number mean?

A: The "A" denotes the initial or first functional revision level of this specific hardware configuration, reflecting its design version within the product lifecycle.

Q5: Can this module be used outside of GE Mark VIe systems?

A: It is specifically designed and optimized for integration within General Electric's Mark VIe turbine control architecture and is not intended for standalone or third-party system use.
