General Electric IC697PWR711 Power Supply Module

Inquiry now

IC697PWR711 Product datasheet

Model number:	IC697PWR711	Module Type：	Power Supply Module
Manufacture:	General Electric	Condition：	Brand New
Range of Product:	Mark VIe	Lead time：	In Stock
Weight:	0.9 kg	HS CODE：	8537101190
Dimension:	20x11.5x5.7cm	MOQ:	1
Product Origin:	USA	System：	DCS
Discontinued on:	Active	Communication Service:	Ethernet router

IC697PWR711 Functional Description

The IC697PWR711 General Electric electronic overvoltage protection circuit is a versatile 100-watt power supply module designed for the Series 90-70 PLC system. This robust unit features flexible input voltage compatibility, supporting operation from 120 VAC, 240 VAC, or 125 VDC sources, with an operational range extending from 90 to 264 VAC and 100 to 150 VDC. The engineering design of it incorporates power factor correction for AC operation and comprehensive electronic protection against short circuits and overcurrent conditions, ensuring reliable performance in industrial environments.

With its triple output configuration, the Programmable Controller Power Supply Module IC697PWR711 General Electric delivers +5 VDC at up to 20 amps, +12 VDC at 2 amps, and -12 VDC at 1 amp, providing complete power solutions for various system components. The modular design of it allows for slide-in rack mounting in the leftmost slot of any standard IC697 rack or VME Integrator's rack, connecting directly through a 48-pin backplane connector. This strategic placement and connection method enable the General Electric IC697PWR711 to efficiently distribute power and logic level sequencing signals throughout the system.

A significant advantage of the IC697PWR711 General Electric Power Supply Module is its capability to power two separate racks simultaneously when the total load remains within the 100-watt rating. The module includes a prewired interconnection cable for this expanded configuration, while maintaining ride-through capability that sustains output for at least one input line cycle during total input power loss at full load. This feature ensures continuous operation during brief power interruptions.

Rated for 135 watts input power at full load, the rack-mounted unit IC697PWR711 General Electric demonstrates high conversion efficiency while requiring appropriate power derating for extended operation at low line voltages and elevated temperatures. The combination of robust construction, flexible configuration options, and comprehensive protection mechanisms makes this power supply module a reliable foundation for industrial automation systems, supporting critical operations in demanding manufacturing and process control applications.
