IC670CHS002 Product datasheet
|
Model number: |
IC670CHS002 |
|
Module Type： |
Terminal Block |
|
Manufacture: |
General Electric |
|
Condition： |
Brand New |
|
Range of Product: |
FANUC |
|
Lead time： |
In Stock |
|
Weight: |
0.74 kg |
|
HS CODE： |
8537101190 |
|
Dimension: |
16.5x9x10cm |
|
MOQ: |
1 |
|
Product Origin: |
USA |
|
System： |
DCS |
|
Discontinued on: |
Active |
|
Communication Service: |
Ethernet router |
IC670CHS002 Functional Description
General Electric IC670CHS002 Terminal Block serves as a critical communication hub within GE's Field Control system, designed to optimize data transfer between Genius Bus networks and I/O modules. This high-performance interface supports the unique wiring architecture of I/O Terminal Blocks, which feature three isolated common terminal groups (A, B, and E) for flexible power distribution and signal routing.
The I/O Terminal Block IC670CHS002 GE enables robust backplane communications while maintaining complete wiring integrity, allowing module replacement without disturbing field connections. Its design complements the terminal block's vibration-resistant screw mounting system, where two modules can be installed on a single block with terminals 1-16 dedicated to I/O wiring.
With the GE IC670CHS002 terminal block, users benefit from the terminal block's isolated E-group (5 common terminals) for specialized application wiring, while the A and B groups handle standard power connections. This configuration ensures clean signal transmission crucial for the module's 1 Mbps data transfer capability in noisy industrial environments.
As part of a complete Field Control solution, the IC670CHS002 PLC Module/Rack by GE FANUC leverages this terminal block architecture to deliver superior communication performance while simplifying installation and serviceability in complex control systems.
If you have other request contact our team to get customized service
Call +86 18159889985 to be connected with our Manager Stella
Email to sales6@apterpower.com get your best quotation
For the quick assistance message us on WhatsApp at +86 18159889985 now!
|
