IC200MDL750 Overview

The General Electric IC200MDL750 Discrete output modules is a 32-point discrete output module. It provides two independent groups of 16 sourcing DC outputs, requiring an external DC power supply to control connected loads.

Environment and Certification

• Hazardous Location: Certified for operation in Class I, Division 2 hazardous locations.

• Mounting Flexibility: Supports installation on a standard 35mm DIN rail in both horizontal and vertical orientations.

• Operating Temperature: Designed for a standard industrial temperature range; performance requires thermal derating beyond 30°C.

• Industrial Durability: Compact and robust construction suitable for distributed industrial I/O systems.

• Electrical Protection: Requires external suppression circuits when switching inductive loads for safe operation.

• Safety Compliance: Meets relevant industrial standards for electrical safety and EMC in automation environments.

FAQ

Q1: What is the total number of output points on the IC200MDL750?

A1: It is a 32-point discrete output module, organized in two groups of 16 channels.

Q2: What type of DC outputs does it provide?

A2: It provides 24VDC sourcing (positive logic) outputs that supply current to connected loads.

Q3: What is the rated current per output channel?

A3: Each output channel can deliver a maximum current of 0.5 Amps.

Q4: Is it suitable for use in hazardous industrial areas?

A4: Yes, the module is certified for use in Class I, Division 2 hazardous locations.

Q5: What special consideration is needed for inductive loads like relay coils?

A5: An external suppression circuit (like a flyback diode) is required when connecting inductive loads to protect the module.
