IC200MDD844 Overview

The General Electric IC200MDD844 Discrete Mixed I/O Module is a VersaMax discrete mixed I/O module. It provides a high-density interface with a maximum of 32 input/output points for flexible system integration.

Features & Benefits

• Mixed I/O Configuration: Integrates 16 sourcing outputs and 16 inputs in one module, saving space and cost.

• High-Speed Response: Offers basic input response times of 0.5ms for fast signal processing.

• Noise Immunity: Provides selectable input filters (0/1/7 ms) for reliable operation in electrically noisy environments.

• Output Drive Capacity: Each output point supplies up to 0.5A to directly control loads like solenoids and lamps.

• Backward Compatibility: Module revisions (e.g., IC200MDD844C) add functionality like 12V negative logic support.

FAQ

Q1: What is the total number of I/O points on the IC200MDD844?

A1: It provides a total of 32 I/O points, combining both inputs and outputs in one module.

Q2: How are the 32 I/O points configured?

A2: They are configured as 16 discrete sourcing outputs and 16 discrete inputs (divided into two groups of 8).

Q3: What is a key feature for dealing with noisy signals?

A3: It features configurable input filters with selectable delay times (0, 1, or 7 ms) to ensure signal stability.

Q4: What is the rated current for its output points?

A4: Each output point can supply up to 0.5 Amps to drive connected loads.

Q5: What is required to use 12V negative logic outputs?

A5: You need a specific module revision, such as the IC200MDD844C or a later version.
