IC200ALG430 Overview

The IC200ALG430 MIXED MODULE General Electric is a versatile analog mixed I/O module. It provides four analog current inputs and two analog current outputs, requiring an external 24VDC power supply for output operation.

Key Features

• I/O Configuration: Integrates four (4) analog current inputs and two (2) analog current outputs in a single-slot module.

• Signal Range: Supports standard 4-20mA signals for both input and output channels.

• High Performance: Offers fast update rates (0.4ms input, 0.3ms output) and 12-bit resolution for precise control.

• Electrical Isolation: Provides 250VAC continuous optical isolation for enhanced safety and noise immunity.

• Power Requirements: Outputs require an external 18-30VDC supply; inputs draw power from user transceivers.

• Diagnostics: Includes LED indicators and reports loss of user-side power for maintenance.

FAQ

Q1: What types of signals does the IC200ALG430 module handle?

A1: It is designed for standard 4-20mA analog current signals on both its input and output channels.

Q2: How many analog channels does it provide?

A2: It provides four (4) analog current inputs and two (2) analog current outputs.

Q3: Is an external power supply required for this module?

A3: Yes, the analog outputs require an external power supply in the range of +18 to +30 VDC to operate.

Q4: What is the resolution and update rate of this module?

A4: It features 12-bit resolution with fast update rates of 0.4 ms for inputs and 0.3 ms for outputs.

Q5: Does it offer protection against electrical noise?

A5: Yes, it provides 250VAC continuous optical isolation between field-side and system-side circuits for safety and noise rejection.
