EMG EVK2.11.2 Overview
The EMG EVK2.11.2 is a non-contact edge positioning system using optical sensors to detect strip edge displacement, enabling precise, automated control of strip guiding with high reliability and interference resistance.
Technical Data Summary
EMG EVK2.11.2 is an optical edge positioning system for non-contact strip guiding applications.
Equipped with HF light measuring sensors (LS 13/14) protected against ambient light.
Provides measuring accuracy of less than 1.0 mm for precise edge detection.
Operates with 24 V DC supply and initial current below 4 A.
Features CANopen interface for integration with control systems.
Designed with IP54 protection and operates in temperatures from 0 to +50 °C.
FAQ
Q1: What is EMG EVK2.11.2 used for?
A1: It is used for non-contact strip edge and center guiding in steel processing applications.
Q2: How does EMG EVK2.11.2 detect strip position?
A2: It uses optical HF light sensors and photocells to detect lateral strip edge displacement.
Q3: Does EMG EVK2.11.2 adjust automatically?
A3: Yes, a control system activates a DC motor or actuator to maintain correct strip positioning.
Q4: How does EMG EVK2.11.2 handle sensor contamination?
A4: It applies a reference measuring principle using a measuring and reference receiver to compensate for contamination.
Q5: What communication interface does EMG EVK2.11.2 support?
A5: It supports CANopen communication for integration with industrial control systems.
